Je bekijkt pagina 23 van 60
Removing the battery
1. Press the unlock button (7) of the battery (5) and re-
move it from the battery mount (6).
9.2 Check the charge status of the
battery
The charge status indicator (28) indicates the charge sta-
tus of the battery (5).
The charge status of the battery is indicated by the corre-
sponding LED light lighting up.
1. Press the charge status indicator button on the battery
(27).
LED on the battery Charging status
red-orange-green Battery full
red-orange Battery partially charged
red Battery empty
9.3 Depleted batteries
• A significantly shortened operating time despite
charging indicates that the battery has been used up
and needs to be replaced. Only use original replace-
ment batteries.
• In any case, observe the applicable safety instructions
as well as regulations and instructions on environmen-
tal protection (see “Disposal and recycling”).
9.4 Charge battery (5)
WARNING
Observe the following information to reduce
hazards:
– Never leave batteries to charge unsupervised!
– Remove rechargeable batteries from the charger af-
ter charging.
– Do not over-charge batteries! Observe the maxi-
mum charging times. These charging times only ap-
ply to discharged batteries. Inserting a charged or
partially charged battery multiple times leads to
overloading and cell damage. Do not leave batteries
in the battery charger for multiple days.
– Never use or charge batteries if you suspect that
they were last charged more than 12 months ago.
The probability is high that the battery is already
dangerously damaged (deep discharge).
Charge the battery at an ambient temperature of 4 °C to
40°C.
1. Push the battery (5) into the battery mount up to the
stop.
2. Plug the mains plug into the socket. The LED strip
(14) lights up green.
3. As soon as the charging process starts, the LED strip
(14) flashes green.
4. The LED strip (14) lights up green when charging is
complete. The battery (5) is ready for use.
ATTENTION
– If the red LED strips flash, the battery has overheat-
ed and cannot be charged.
– If the LED strip flashes red and green alternately,
the battery is defective.
5. Pull the battery (5) out of the battery holder.
6. Wait at least 15 min until a new charging process.
Therefore, pull the mains plug out of the outlet.
9.5 Inserting/removing the tool
attachment
WARNING
Tool attachments may be sharp and become hot during
use. Always wear protective gloves when handling the
tool attachments.
CAUTION
Keep your hands away from the tool attachment when
the product is in operation.
1. Turn the quick-release chuck (2) anti-clockwise until
the chuck opening (1) is large enough to insert the
tool attachment.
2. Insert the tool attachment into the quick-release chuck
(2) as far as possible.
3. Turn the quick-release chuck (2) clockwise to clamp
the tool attachment tight.
4. To remove the tool attachment again, untwist the
quick-release chuck (2) and remove the tool attach-
ment.
9.6 Test run (Fig. 1)
Note:
Before the first work and after each tool attachment
change, carry out a test run without load. Switch off the
product immediately if the tool attachment runs out of
round, there is considerable vibration or abnormal noises
are heard.
1. Before operation, check whether the tool attachment
is properly attached, i.e. centred in the quick-release
chuck (2).
2. Screw bits are marked with their dimensions and
shape. If you are unsure, always try out first whether
the bit sits in the screw head without play.
9.7 Gear selection (Fig. 1)
1. Push the gear selector switch (4) to 1 or 2 corre-
sponding to a low or high speed selection.
Gear 1 :
0 - 400 rpm
Suitable for: Screwing work
Rotational speed: Low
Torque: High
Gear 2 :
0 - 1550 rpm
Suitable for: Drilling work
Rotational speed: High
Torque: Low
