GB
|
41
Remove the spark plug (10) with a spark plug wrench.
Use a feeler gauge to set the gap to 0.75 mm( 0.030”).
Replace the spark plug (10) and take care not to tight-
en it too rmly.
Engine brake lever (3) (Fig. 1)
The engine is equipped with a mechanical brake
which has to be checked regularly. When the brake
lever (3) is released, the blade must come to a stand-
still within 7 seconds; if this is not the case, the appli-
ance must not be used. Contact an authorised spe-
cialist dealer.
Ensure that the product is in a awless condition for
its entire service life. Improper maintenance may lead
to life-threatening injuries.
Repairs
After repairs or maintenance, make sure that all safe-
ty-related parts are installed and are in perfect con-
dition. All parts which may cause injury must be kept
where they are inaccessible to children or others.
Attention: According to the German Product Liabili-
ty Act, no liability is accepted for damage caused by
improper repairs or by not using original spare parts.
Such work should be performed by a customer ser-
vice centre or an authorised specialist. The same ap-
plies to accessory parts.
Operating times
Please comply with statutory regulations to lawn-
mower operating times, which may vary from location
to location.
Please provide the following information in the
event of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Motor data - type plate
Important note in the case of repairs:
For return delivery of the device for repair, please en-
sure for safety reasons that it is free of oil and fuel
when it is sent to the service centre.
Spare parts / accessories
Lawnmower blade - Article no.: 7911200618
Service information
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wearing parts*: Spark plug, air lter, fuel lter, blade,
V-belt, battery
* may not be included in the scope of delivery!
• Pull out the oil dipstick (12) and read the oil level
horizontally. The oil level must be positioned be-
tween the max and min of the oil dipstick (12).
Oil change (Fig. 23)
• The engine oil change should be completed annu-
ally before the start of the season while the engine
is at operating temperature and shut o.
• Only use motor oil (SAE 30).
• Empty the fuel tank (6) (with a petrol extraction
pump).
• Place a at oil collecting tray in front of the mower
(min. volume 1 litre).
• Unscrew the oil dipstick (12) and tilt the mower until
all the oil has drained into the collection tray.
• Then ll in fresh engine oil up to the upper mark
of the oil dipstick (12) (approx. 0.5 l), do not overll
the device.
• Attention! To check the oil level, do not screw in the
oil dipstick (12), but only insert it up to the thread.
Dispose of the used oil in accordance with applicable
regulations.
Cleaning the belts (Fig. 17, 19)
• Remove the blade and the transmission housing by
undoing the screws.
• Clean the elements of the transmission and the
V-belt once or twice a year with a brush or com-
pressed air.
• Ret the transmission housing and the blade using
the screws.
Maintaining and adjusting the cables
Oil the cables at regular intervals and check that they
move easily.
Air lter maintenance (7) (Fig. 20)
Fouled air lters diminish the engine output due to
reduced air supply to the carburettor. Regular inspec-
tion is therefore essential.
The air lter (7) should be checked every 25 operat-
ing hours and cleaned as required. The air lter (7)
must be checked more often if the air is very dusty.
Unclip the air lter cover and remove the sponge lter
element. Replace the air lter to avoid objects falling
into the air intake (g. 20).
Attention: Never clean the air lter with petrol or com-
bustible solvents. Clean the air lter with compressed
air or simply by knocking out any soiling.
Spark plug maintenance (10) (Fig. 21)
Check the spark plug (10) for contamination for the rst
time after 10 operating hours and clean it with a cop-
per wire brush if necessary. Then maintain the spark
plug (10) every 50 operating hours.
Remove the spark plug connector with a twist.
