www.scheppach.com
18
|
GB
2. Loosen the fastening screws with the Phillips
screwdriver.
3. Slide the hose stopper (1) along the compressed
air hose (2) to the desired position.
4. Tighten the fastening screws again.
11. Transport
• Secure the product against slipping when transport-
ing it in a vehicle.
• If possible, use the original packaging for transport.
12. Maintenance, cleaning and storage
WARNING! Danger of injury! Do not open the hous-
ing. There is a return spring inside, which can spring
out when opened.
Disconnect the hose reel from the compressed air
source before starting maintenance.
• If the hose (2) is dirty, clean it before rolling it up.
Never use aggressive cleaning agents for this!
• Regularly check the leak-tightness of the hose (2).
• Lubricate the moving parts of the hose reel regularly.
• Replace defective and damaged parts immediately.
• When not in use, roll up the hose (2) completely and
store it in a dry, clean and frost-proof place.
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consumables.
Wearing parts*: Hose
* may not be included in the scope of delivery!
Please provide the following information in the event
of any queries:
• Type plate data
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.
13. Disposal and recycling
Notes for packaging
The packaging materials are recycla-
ble. Please dispose of packaging in
an environmentally friendly manner.
1. Connect the air hose reel to the compressed air
supply by engaging the plug nipple (6) into the
quick-release coupling of the compressor.
2. Disconnect the air hose reel from the compressed
air supply by pulling the outer ring of the quick cou-
pling away from the air hose reel.
10.2 Locking and return mechanism
The air hose reel has a locking and return mecha-
nism. This makes it easy to pull out and return the com-
pressed air hose.
This locking mechanism makes a creaking noise when
rolling up and down. This is not a fault. If the noise
changes after numerous uses and/or if there are prob-
lems with the mechanism, seek professional help or
contact customer service.
WARNING! Danger of injury!
• The return mechanism is operated by a powerful
spring. Injuries can occur if the compressed air hose
is rolled up incorrectly.
• Never allow the compressed air hose to recoil un-
controllably.
• If the return mechanism is damaged, take the air
hose reel out of operation immediately. Have the
damage repaired by a specialist.
10.3 Unreeling the hose
1. Carefully pull the compressed air hose (2) out of the
reel housing (4) to the desired working length for the
pneumatic tool. When you release the compressed
air hose (2), the lock engages at this length.
10.4 Reeling in the hose
1. You can release the lock by pulling the com-
pressed air hose (2) briey (approx. 3-5 cm).
2. Ensure that you roll the compressed air hose (2)
back into the reel housing (4) in a controlled man-
ner. To do this, hold the quick-release coupling
while pulling it in.
3. If the hose becomes twisted, it is necessary to ex-
tend the hose to its full length so that it can retract
evenly into the reel.
10.5 Adjusting the hose stopper
The position of the hose stopper (1) can be adjusted -
this stops the winding of the compressed air hose (2) at
the desired length.
1. A Phillips screwdriver (not included in the scope of
delivery) is required to adjust the hose stopper (3).
