20 Set inputs and outputs
• Tap "Unit" to select the atmospheric pressure unit.
• Tap "Atmo pressure" to enter a value. This value must be between:
• 0 and 4000 hPa
• 0 and 4000 mbar
• 0 and 3000.24 mmHg
• 0 and 10 000 m (altitude)
9.3.3 Congure the differential pressure module
Select the measuring device:
"I/O Congurations" menu is displayed.
• Tap "Probes & Modules".
The screen displays the connected probes and modules.
• Tap the line corresponding to the pressure module.
• Tap "Device".
• Tap "Type".
• Tap the desired measurement mean between:
• Pitot tube L (coefcient: 1.0015)
• Pitot tube S (coefcient: 0.84)
• Debimo blades (coefcient: 0.8165)
• Other (free coefcient)
If "Other" is selected, the coefcient of the other measurement mean should be entered. This coefcient
must be between 0.0001 and 9.9999.
• Tap the back arrow on the left of the screen to back to conguration menu.
Select the type of duct section:
"I/O Congurations" menu is displayed.
• Tap "Probes & Modules".
The screen displays the connected probes and modules.
• Tap the line corresponding to the pressure module.
• Tap "Section".
• Tap "Shape".
• Tap the requested section:
• Rectangular
• Circular
• Custom coefcient
For a rectangular section:
• Tap "Unit" to select the unit: mm or in, then tap the back arrow on the top left of the screen.
• Enter the length and width of the section.
Length and width of the section must be between 1 and 3000 mm (0.039 to 118.11 in).
For a circular section:
• Tap "Unit" to select the unit: mm or in, then tap the back arrow on the top left of the screen.
• Enter the diameter.
Diameter of the section must be between 1 and 3000 mm (0.039 to 118.11 in).
For a custom coefcient (airow coefcient):
