Set inputs and outputs 19
• Tap the required value.
The values proposed will depend on the type of output previously selected. For example, if the output type
is 4-20 mA, proposed values will be 4 mA, 12 mA and 20 mA.
If the deviations are too large (> 0.05 V or > 0.05 mA) between the signal issued and the value
displayed on the multimeter, we recommend that you return the transmitter to our factory.
9.2.3 Set the digital output (Modbus RTU)
"I/O Congurations" menu is displayed.
• Tap "Outputs".
• Tap "Digital Outputs".
Features of Modbus are displayed.
• Tap "Slave address".
• Dene the slave address number between 1 and 255 then tap the back arrow on the top left of the screen.
• Tap "Baud rate".
• Select the baud rate between 2400, 4800, 9600, 19,200, 38,400, 57,600, 76,800 and 115,200 then tap the
back arrow on the top left of the screen.
Default baud rate: 9600
9.3 Set the probes and the pressure module
This menu allows to dene relevant values related to the probes and the pressure module connected to the transmit-
ter and dene some parameters linked to them:
• For an air velocity probe (hotwire probe): duct dimensions and type of section, the correction factor, the inte-
gration in air velocity and the compensation in atmospheric pressure for airow calculation.
• For the pressure module: for air velocity and airow calculation the duct dimensions and type of section, the
airow coefcient, the pressure probe coefcient, the integration in pressure and autozero duration.
• For a CO
2
probe: the compensation in atmospheric pressure
• For an hygrometry probe: the compensation in atmospheric pressure for the psychrometry calculations
9.3.1 Normative values
For the airow calculations, it is possible to convert the value into normative values (ex: Nm³/h).
The conversion can be done according to two standards:
• DIN 1343: 1013.325 hPa, 273,15 K (0°C)
• ISO 2533: 1013.325 hPa, 288,15 K (15°C)
"I/O Congurations" menu is displayed.
• Tap "Probes & Modules".
The screen displays the connected probes and modules.
• Tap "Normative values".
• Select the normative value according to your needs: DIN 1343 or ISO 2533 then tap the back arrow on the top
left of the screen.
9.3.2 Congure the compensation of a CO
2
or hygrometry probe
A CO
2
or hygrometry probe must be connected to the transmitter.
Set the compensation in atmospheric pressure:
"I/O Congurations" menu is displayed.
• Tap "Probes & Modules".
The screen displays the connected probes and modules.
• Tap the line corresponding to the temperature/hygrometry probe or to the CO
2
probe.
• Tap "Atmo pressure".
