Transmitter features 15
7.3 Dimensions
100 mm (3.94’’)
234 mm (9.21’’)
218 mm (8.58’’)
76 mm (3’’)
44 mm (1.73’’)
47 mm (1.85’’)
80 mm (3.15’’)
185.5 mm (7.28’’)
7.4 Possible optional measurements
The following probes and modules are available as an option for Si-CPE320 transmitters. For further details please
see the probes technical data sheet for class 320 transmitters.
Probes / modules Measuring ranges Calculated parameters
Relative humidity /
temperature probe
0 to 100 %RH and -40 to 150 °C (-40 to
302 °F) (according to the probe)
Dew point: -50 to 100 °C
td
(-58 to 212 °F
td
)
Wet-bulb temperature: -50 to 100 °C
tw
(-58 to 212 °F
tw
)
Frost point: -50 to 100 °C
tf
(-58 to 212 °F
tf
)
Enthalpy: 0 to 15,000 kJ/kg
Absolute humidity: 0 to 1000 g/m³
Mixing Ratio: 0 to 1000 g/kg
Temperature probe -80 to 150 °C (-112 to 302 °F) N/A
Air velocity / temper-
ature probe
0 to 30 m/s (0 to 98.4 fps) and 0 to 50 °C
(32 to 122 °F)
Air ow: 0 to 999,999 m³/h (0 to 588,577cfm)
Air change rate: 0 to 1000 ACH
CO probe 0 to 500 ppm N/A
CO
2
probe 0 to 10,000 ppm N/A
VOC probe
TVOC: 0 to 1000 ppb
CO
2
eq: 400 to 2000 ppm
N/A
