4.5. Configure the Modbus communication (optional)
Modbus option must be activated (see chapter 4.6).
4.5.1 Set the slave number: F150
F141 sub-folder is displayed.
Press Up key.
“F 150” is displayed.
Press OK.
“F 150” blinks with the serial number below (e.g: 255).
Press OK.
The 1
st
digit of the slave number blinks.
Press Up and Down keys to modify it then press OK.
The 2
nd
digit of the slave number blinks.
Press Up and Down keys to modify it then press OK.
The 3
rd
digit of the slave number blinks.
Press Up and Down keys to modify it then press OK.
“F150” blinks with the selected slave number below.
4.5.2 Set the speed communication: F151
Press Up or Down key to go to F151 sub-folder.
Speed communication in bits per second is displayed (e.g: 9600).
Press OK.
The speed communication blinks.
Press Up and Down keys to select the required speed communication between the following values:
2400 bds
4800 bds
9600 bds
19.2 Kbds
38.4 Kbds
115.2 Kbds
Press OK.
“F151” blinks with the selected speed communication below.
4.6. Activate the options
To activate an option, an activation code is necessary. This code is provided by the manufacturer.
Available options for CPE310 are the high resolution in pressure (F170 sub-folder) (only for CPE
310-S) and Modbus (F171 sub-folder).
- High resolution in pressure option: F170
“F 150" sub-folder is displayed.
Press Up key.
“F 170” blinks and “0” is displayed below, meaning the option is not activated.
Press OK.
“0” blinks.
Press Up key.
The transmitter asks for an activation code.
Enter the activation code (same procedure as for the safety code) then press OK.
“F 170” blinks and “1” is displayed below, meaning the option is activated.
F 100: Congure the transmitter
11
