Checking the ame quality:
All combustion ames need to be visually checked to determine their ame
quality.
2
3
1
1. Soft blue ames — Normal for natural gas
operation.
2. Yellow tips on outer cones — Normal for
LP gas operation.
3. Yellow ames — Abnormal for any gas
operation; call for service.
NOTE
If burner ame looks like 3, the range
should not be used until it is serviced.
Call for service. Normal burner ames shall
look like 1 or 2, depending on the gas type
you use.
Step 9. Final installation checklist
You have just completed installing your range. Make sure all controls are in the off
position and the ow of ventilation air to the range is unobstructed. The following
is a checklist to conrm your range is safely installed and ready for operation.
Gas Range Plug
Locking screw
• Gas line has been properly connected to
the range. The gas has been turned on.
All connections have been checked for
leaks.
• Range is plugged into the properly
grounded electrical receptacle.
• Approved anti-tip bracket is properly
installed and engaged with the range.
• Range is leveled and is rmly sitting on a
solid, level oor.
• Gas surface burners have been properly
assembled.
• All burners have been tested for proper
operation.
• FOR INSTALLER ONLY—Check and/
or adjust the broil and oven burner ames
as described on pages 22 - 23 in this
manual.
Adjusting the oven burner air adjustment shutters
Air
adjustment
shutter
All oven burners have an air adjustment
shutter. The purpose of the shutter is to
regulate the ow of air to the ames.
Properly adjusted ames should burn
steadily with approximately 1 in of blue
cone. The ames should never extend
past the edge of the burner bafes. Even
though these are preset at the factory, they
should be checked and, if needed, adjusted
periodically to ensure efcient operation.
