English 23
Installation instructions
Step 7. Assemble the surface burners
CAUTION
Do not operate the surface burners without
all burner parts in place.
1. Position surface burner heads on top of
the surface burner manifolds as shown at
right. The electrodes will t into the slot
in the bottom of the heads. Make sure the
surface burner heads are at and parallel
with the cooktop.
2. Place the matching size caps on top of
each surface burner head.
Precise Simmer Burner (RR)
Flat surface Concave line
NOTE
The caps on Precise simmer burner
(RR) and inside Dual Burner (RF) can be
interchangeably used.
3. Place the left, center, and right surface
burner grates on the cooktop.
The edges of the grates should match up
with the edges of the cooktop.
Step 8. Check the ignition of surface burners
Check the operation of all cooktop and oven burners after the range has been
installed and assembled, gas supply lines have been carefully checked for leaks,
and electrical power cord has been plugged in.
All surface and oven burners have electronic ignition.
3
2
1
1
To turn on a surface burner:
1. Press the button integrated into the knob.
2. Push in and turn the control knob for that
surface burner to the Lite position. The
"clicking" sound indicates the electronic
ignition system is operating properly.
The burner will light in about 4 seconds,
after the air has been purged from the
supply line.
3. After the burner lights, turn the control
knob to the desired setting. The "clicking"
sound will stop and the ame height will
change from Max. to Min. during turning
the control knob.
4. Repeat steps 1, 2, 3 to check the
operation of each surface burner in
succession.
NOTE
Place food in the oven after preheating
if the recipe calls for it. Preheating is
important for good baking results. After
the oven has reached the desired cooking
temperature, it will beep.
