English-39
INSTALLATION05
Installing and connecting the drain hose of the indoor unit
• Thehosewillbexedpermanentlyintopositionafternishingtheinstallationandthegasleaktest;
refer to page 43 for further details.
• Makesuretheinstalleddirectionofthedrainhoseiscorrect.
Inadequate installation may cause condensate water leakage.
• Ifthedrainhoseisroutedinsidetheroom,insulatethehosesothatdrippingcondensationdoesnotdamagethe
furniture or oors.
• DONOTWALLUPTHEDRAINHOSECONNECTION!
Drain hose connection must be easy accessible and serviceable.
6. Pass the drain hose under the refrigerant pipe, keeping the drain hose tight.
7. Pass the drain hose through the hole in the wall. Check if it slants
downwards as seen in the picture.
8. Using natural drainage method, check the drainage is normal.
Shield
Drain hose Extension drain hose
Changing direction of the drain hose
• Makesuretheindoorunitisinuprightpositionwhenyoupourwatertocheckforleakage.
Make sure that the water does not overow onto the electrical part.
Change the direction only when it is necessary.
1. Detach the rubber cap with the pliers.
2. Detach the drain hose by pulling it and turning to the right.
3. Insert the drain hose by xing it with the screw into the groove of the drain hose and the outlet of the drain pan.
4. Attach the rubber cap with a screwdriver by turning it to the left until it xes to the end of the groove.
5. Check for leakage on both side of the drain outlet.
Pour the water in direction of arrow.
Direction of the drained water
Drain hose
Screw
Screw hole
Rubber cap
Drain pan outlet
IB&IM_EN_DB98-33330A-08.indd 39 11/3/2015 8:45:41 AM
