Installation Procedure

05 series installation option (Detailed)

Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX

Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6

Explanation

PAGE MODE

Use of Auto Change

Over for HR only in

Auto mode / Use of

Cooling only indoor

unit of HR

(When setting

SEG3) Standard

heating temp.

Offset

(When setting

SEG3) Standard

cooling temp.

Offset

(When setting

SEG3) Standard

for mode change

Heating → Cooling

Indication

and

Details

Indication Details

Indication

Details

Indication

Details

Indication

Details

Indication

Details

Indication

Details

0 5

product

option

0 0 °C 0 0 °C 0 1 °C

1 0.5 °C 1 0.5 °C 1 1.5 °C

Use Auto

Change

Over for

HR only

2 1 °C 2 1 °C 2 2 °C

3 1.5 °C 3 1.5 °C 3 2.5 °C

4 2 °C 4 2 °C 4 3 °C

Use

Cooling

only

indoor unit

for HR

5 2.5 °C 5 2.5 °C 5 3.5 °C

6 3 °C 6 3 °C 6 4 °C

7 3.5 °C 7 3.5 °C 7 4.5 °C

Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12

Explanation

PAGE

(When setting

SEG3) Standard

for mode change

Cooling → Heating

(When setting SEG3)

Time required for

mode change

Compensation

option for Long pipe

or height difference

between indoor units

MTFC (*3) -

Indication

and

Details

Indication Details

Indication

Details

Indication

Details Indication Details Indication

Details -

0 1 °C 0 5min 0 Default

Default -

1 1.5 °C 1 7min

(*1) Height

difference

is more

than 30m

or (*2)

Distance

is longer

than 110m

2 2 °C 2 9min

3 2.5 °C 3 11min

4 3 °C 4 13min

(*1) Height

difference

is 15~30m

or (*2)

Distance is

50~110m

2 Use -

5 3.5 °C 5 15min

6 4 °C 6 20min

7 4.5 °C 7 30min

DB68-13032A-00_IBIM_DVM R32 WindFree 1,4way_EU_EN_.indd 53DB68-13032A-00_IBIM_DVM R32 WindFree 1,4way_EU_EN_.indd 53 2024-07-29 오전 10:10:532024-07-29 오전 10:10:53
