Refrigerant pipe installation
English
Installation Procedure
• Amount of additional refrigerant for each indoor unit ( )
(Unit: kg)
Capacity (kW)
Model
1.5 1.7 2.2 2.8 3.6 4.5 5.6 6 7.1 8.2 9 9.3 11.2 12.8 14 16 18 22 22.4 28 32 50
500
CMH
1000
CMH
Slim 1way cassette (JSF)
(AM****N1DEH*)
0.25 0.25 0.25 0.32 0.32
Interior 1way cassette
(AM***HN1DEH*)
(AM***NN1PEH*)
0.15 0.15
2way cassette
(AM***FN2DEH*)
0.31 0.47
4way cassette S
(AM***FN4DEH*)
(AM***NN4DEH*)
0.45 0.45 0.45 0.45 0.57 0.69 0.69
360 cassette
(AM***KN4DEH*)
0.45 0.45 0.45 0.45 0.69 0.69 0.69
Floor Standing Unit
(AM***FNFDEH*)
0.22 0.32 0.32
ERV plus
(AM***FNKDEH*)
0.11 0.36
4way cassette
S (600x600)
(AM***FNNDEH*)
(AM***NNNDEH*)
0.29 0.29 0.29 0.29 0.37 0.37 0.37
Slim duct
(AM***FNLDEH*)
0.17 0.17 0.17 0.26 0.35 0.35 0.45 0.42 0.42 0.62 0.62
Home duct
(AM***MNLDEH*)
(AM***KNLDEH*)
0.13 0.13 0.13 0.17 0.24 0.24 0.31
MSP duct(MA duct)
(AM****NMDEH*)
0.24 0.24 0.24 0.28 0.28 0.28 0.32 0.54 0.68 0.68 0.91
MSP duct(Duct S)
(AM***ANMPKH*)
0.45 0.45 0.45 0.45 0.8 0.84 0.84 0.84
Ceiling
(AM***FNCDEH*/
AM***JNCDKH*)
0.39 0.39 0.56 0.95
Console
(AM****NJDEH*)
0.16 0.27 0.27 0.27 0.27
Neo forte
(AM***FNTDEH*)
0.24 0.24 0.24 0.24 0.36 0.36
Neo forte (with EEV)
(AM***FNQDEH*)
0.34 0.34 0.34 0.34 0.51 0.51 0.51
Boracay
(AM***KNTD*H*)
0.24 0.24 0.32 0.32 0.49 0.49 0.49
Boracay (with EEV)
(AM***KNQD*H*)
0.24 0.24 0.32 0.32 0.49 0.49 0.49
AR5000
(AM***JNAD*H*)
0.16 0.16 0.19 0.25 0.25 0.52 0.52 0.52
AR5000 (with EEV)
(AM***JNVD*H*)
0.22 0.22 0.25 0.34 0.34 0.71 0.71 0.71
MAX4 (with EEV)
(AM***MNQD*H*)
0.68
QMD RAC (with EEV)
(AM***TNVDKH*)
(AM***TNQDKH*)
0.23 0.23 0.32 0.32 0.48 0.48 0.48 0.64
HSP duct
(AM***FNHDEH*)
0.68 0.68 0.68 1 .18 1 .18
HSP duct (Duct S)
(AM***ANHPKH*)
0.84 0.84 0.84
Big duct
(AM***JNH*KH*)
1 .15 1 .15
OAP duct
(AM****NEP*H*)
0.68 1.18 1.18
PAC (AM***JNPDKH*) 0.69 1 .85
Hydro Unit HE
(AM****NBDEH*)
0.60 0.70 1.20
Hydro Unit HT
(AM***TNBF*B*)
0.60 note
1)
PAC (AM***JNPDKH*) 0.69 1 .85
※ If there is no additional refrigerant value for the indoor unit in the above table, refer to the indoor unit installation manual.
