26
Installation Procedure
Installation Procedure
English
12.5<P≤15 01117C-1C0436-27A000-370060
15<P≤17.5 01117C-1C0458-27A000-370060
17.5<P≤20 01117C-1C048E-27A000-370060
NOTE
represents E. S. P(External Static Pressure) range
of factory setting.
You don’t have to adjust the fan speed separately
if the external static pressure of the installation
place is in . When it is out of , input the
appropriate option code.
If you input the inappropriate option code, error may
occur or the air conditioner is out of order. The option
code must be inputted correctly by the installation
specialist or service agent.
EASY Tuning
If the more cooling and heating airflow rate which set up when
installing is wanted, or if the more Silent operation which sets
up when installing is wanted, air conditioner is tuned for comfort.
Indoor unit airflow rate for high, mid, low mode increases or
decreases for +2 ~ -2 Steps with wired remotecontrol.
Main Menu Sub-menu
1 2 35 46
Data bit
1 Press the User Set button.
(Main Menu) will be displayed, and you can press the
[ ]/[ ] buttons to select No. 8, which will set the Easy
Tuning.
2 Press the [ ] button to select airflow step.
Press the [ ]/[ ] buttons to select airflow step(-2,-
1,0,1,2) tuning (During the Easy Tuning setting, AC Fan
Speed icon will be displayed)
3 Press the button to complete the Easy Tuning.
(When the Easy Tuning setting complete, AC Fan Speed
icon will be off)
4 Press the button to to exit to normal mode.
Main
menu
Sub
menu
Functions
SEG
used
Default Range
8 -
Easy
Tuning
1,2 0
-2 : -2 Step
-1 : -1 Step
0 : No Use
1 : +1 Step
2 : +2 Step
NOTE
Press the button anytime during setup to exit
without setting.
According to airflow changed from the Easy Tuning, Air
