Installation Procedure

Installation Procedure

Installation Procedure

Step 1 Choosing the installation location

Installation location requirements

• Donotplacetheoutdoorunitonitssideorupside

down.Failingtodosomaycausethecompressor

lubricationoiltorunintothecoolingcircuitand

leadtoaseriousdamagetotheunit.

• Installtheunitinawell-ventilatedlocationaway

fromdirectsunlightorstrongwinds.

• Installtheunitinalocationthatwouldnot

obstructanypassagewaysorthoroughfares.

• Installtheunitinalocationthatwouldnot

inconvenienceordisturbyourneighbors,asthey

couldbeaffectedbythenoiseortheairflow

comingfromtheunit.

• Installtheunitinalocationwherethepipesandthe

cablescanbeeasilyconnectedtotheindoorunit.

• Installtheunitonaflat,stablesurfacethatcan

withstandtheweightoftheunit.Otherwise,theunit

cangeneratenoiseandvibrationduringoperation.

• Installtheunitsothattheairflowisdirected

towardstheopenarea.

• Maintainsufficientclearancearoundtheoutdoorunit,

especiallyfromaradio,computer,stereosystem,etc.

Fuse

Remote control sensor

1 m or more

1 m or more

1.5 m or more

1.5 m or more

Stereo

Computer etc

Outdoor Unit

200 mm

Air Guide Duct (This product is not provided by Samsung)

Indoor Unit

300 mm

• Installtheunitataheightwhereitsbasecanbe

firmlyfixedinplace.

• Makesurethatthewaterdrippingfromthedrain

hoserunsawaycorrectlyandsafely.

CAUTION

• Youhavejustpurchasedasystemair

conditionerandithasbeeninstalledbyyour

installationspecialist.

• Thisdevicemustbeinstalledaccordingtothe

nationalelectricalrules.

• Ifyouroutdoorunitexceedsanetweightof60

kg,donotinstallitonasuspendedwall,but

standitonafloor.

• Wheninstallingtheoutdoorunitattheseaside,

makesurethatitisnotdirectlyexposedtosea

breeze.Ifyoucannotfindanadequateplacefree

fromdirectseabreeze,constructaprotectionwall

oraprotectivefence.

– Installtheoutdoorunitinaplace(suchas

nearbuildingsetc.)whereitcanbeprevented

fromseabreeze.Failuretodosomaycausea

damagetotheoutdoorunit.

Sea breeze Sea breeze

Sea Sea

Outdoor Unit Outdoor Unit

• Ifyoucannotavoidinstallingtheoutdoorunitat

theseaside,constructaprotectionwallaroundto

blocktheseabreeze.

• Constructaprotectionwallwithasolidmaterial

suchasconcretetoblocktheseabreeze.Make

surethattheheightandthewidthofthewallare

1.5timeslargerthanthesizeoftheoutdoorunit.

Also,secureaspacelargerthan700mmbetween

theprotectionwallandtheoutdoorunitfor

exhaustedairtoventilate.

Protection wall

Outdoor Unit

Sea breeze

Sea
