9 — English
To stop the flow of liquid at the spray wand, release the
trigger.
Turn the control knob completely counterclockwise to
turn the sprayer OFF.
LOCK-ON
See Figure 9.
The lock-on feature is convenient when spraying for an ex-
tended period of time or when covering a large area.
To lock-on, squeeze the trigger and slide the locking tab
backward.
To release the lock-on, squeeze the trigger and slide the
locking tab forward.
NOTE: Make sure the trigger is not locked on before
inserting the battery pack into the sprayer.
ADJUSTING THE CONE SPRAY NOZZLE
See Figure 10.
The cone spray nozzle can be adjusted from a stream to a
cone spray.
Remove the battery pack from the tool.
Loosen the nozzle for a stream.
Tighten the nozzle for a cone spray.
USING THE SPRAYER
See Figure 11.
WARNING:
Improper application of cleaning solution can result in
SEVERE INJURY or DEATH. Follow CDC and EPA guide-
lines for cleaning. Follow the chemical manufacturer’s
safety instructions and guidelines listed on the SDS sheet.
WARNING:
Risk of fire or explosion. Spray area must be well-
ventilated and away from sparks or flames.
Install the battery pack into the tool.
Turn the control knob clockwise to turn the sprayer ON.
Set desired pressure.
Slip arm through harness strap and onto shoulder, then
repeat for the other shoulder. Adjust the straps to a com-
fortable position.
Direct the sprayer nozzle directly at the surface areas
you wish to treat.
NOTE: Make sure to stand far enough from the object
being sprayed to prevent the spray from splashing back
onto you.
Squeeze and hold the switch trigger while the unit primes.
This may take several seconds. Continue holding the
trigger until unit begins to spray.
If there is an issue with unit priming, completely fill the tank
with warm, soapy water (common dish soap will work),
squeeze and hold the trigger until the unit begins to spray.
Spray on a dry surface using long, even, overlapping
strokes.
NOTE: While the sprayer is in use some dripping from
the nozzle may occur, this is to be expected.
Release the trigger to stop the spray.
When you are finished with the sprayer, take off the
shoulder harness.
Turn off the sprayer and remove the battery pack.
Unscrew the cap and remove it from the tank.
Return any unused fluid to its original container, and
thoroughly clean the sprayer.
Thoroughly clean the sprayer and tank before transport-
ing or storing the unit and before switching to a different
chemical. See Cleaning the Unit later in this manual.
NOTE: Wipe the outside of the tank with a dry cloth and
clean up any spills before inserting the tank.
Thoroughly wash your hands and any area where skin
has been exposed to the spray.
OPERATING TIPS
Never point the spray end of the wand at yourself or
others.
Avoid spraying on windy days. Spray can be accidentally
blown onto plants or objects that should not be sprayed.
Never spray in the direction of people or animals; always
spray downwind.
Never smoke, eat, or drink while operating the sprayer.
Especially in warmer weather, use sprayer in the early
morning or late afternoon. Excessive heat can evaporate
the mist before it settles.
OPERATION
