4 Russound AW70V6mk2 70V Surface Mount Indoor/Outdoor Speaker Installation Manual
WIRING INFO - 70V/100V OPERATION
Speaker cable
Wiring speakers for 70V/100V systems is simple and easy. A
single run of 2-conductor, stranded wire is run to every speaker
location leaving a small loop (2-3 feet is usually more than
sucient depending on the speakers and their mounting type)
at each speaker location. You can place additional loops for
future expansion or for making speaker location changes if
needed.
Note: This is very dierent from typical low-impedance wiring
used for residential audio installations where a dedicated run
of wire goes from each speaker back to the amplier/receiver.
70V/100V wiring uses much less wire and the wire used can be
a much higher gauge (thinner wire) even though it is used in a
longer run.
Here is a chart showing some of the dierences possible
among wire lengths for both low impedance (4Ω-8Ω) and high
impedance (70V/100V) systems:
Speaker Cable Length for Various Gauges at Low and High Impedance
Power Loss in Cable (% Loss & dB Loss)
4 Ohm Speakers 8 Ohm Speakers 70V Speakers
11% 21% 50% 11% 21% 50% 11% 21% 50%
0.5 dB 1 dB 3 dB 0.5 dB 1 dB 3 dB 0.5 dB 1 dB 3 dB
277’
84m
571’
174m
1930’
588m
554’
169m
1141’
348m
3859’
1.2km
2.6mi
4.14km
5.3mi
8.5km
18mi
29km
174’
53m
359’
109m
1214’
370m
349’
106m
718’
219m
2428’
740m
1.6 mi
2.6km
3.4 mi
5.5km
11.3 mi
18.1km
110’
33.5m
226’
69m
764’
233m
219’
67m
452’
138m
1528’
466m
1mile
1.6km
2mi
3.4km
7mi
11.4km
69’
21m
142’
43m
480’
146m
138’
42m
284’
87m
959’
292m
3376’
1km
1.3 mi
2.1km
4.5mi
7.2km
43’
13m
89’
27m
302’
92m
87’
27m
179’
55m
604’
184m
2127’
648m
4380’
1.3km
2.8mi
4.5km
27’
8m
55’
17m
185’
56m
53’
16m
110’
38m
371’
113m
1305’
398m
2687’
819m
1.7mi
2.8km
17’
5m
35’
11m
117’
36m
34’
10m
69’
21m
234’
71m
823’
251m
1694’
516m
1mi
1.75km
11’
3m
22’
7m
74’
23m
21’
6m
44’
13m
147’
45m
518’
158m
1068’
331m
3610’
1.1km
7’
2m
13’
4m
46’
14m
13’
4m
27’
8m
91’
28m
321’
98m
661’
201m
2234’
681m
4’
1m
9’
3m
29’
9m
8’
2m
17’
5m
57’
17m
202’
62m
417’
127m
1409’
429m
AWG
6
8
10
12
14
16
18
20
22
24
Note: Unlike traditional residential audio, 70V/100V systems
are typically run in mono sound so that only a single two-
conductor wire run is necessary for the speakers. If you want
to use multiple wire runs for zoning speakers or other purposes,
each 2-conductor wire needs to be independently run back to
its own amplier or amplier terminals if using a multi-channel
amplier.
1. At each speaker location, cut the loop of wire at the speaker
location
2. Strip 1 to 2 inches (2.5 to 5 cm) o the end of the cable jacket.
Then strip ½-inch (1.3 cm) of insulation o each wire.
3. Twist the wire strands together so there are no strands
separated from the bundle.
4. Connect the wires to the speaker terminals, being sure to
observe proper polarity. For standard speaker cable with red
and black wires, connect both red wires (the red wire coming
from the 70V/100V connection on the amplier or the previous
speaker if there was one AND the red wire going to the next
speaker if there is an additional speaker) to the red positive
(+) terminal and both black wires (the black wire coming from
the COM connection of the 70V/100V amplier or the previous
speaker if there was one AND the black wire going to the next
speaker if there is an additional speaker) to the black negative
(–) terminal.
Note: Some speaker cables may have other ways of designating
polarity. Cable with a clear jacket has a copper-colored wire for
positive and a silver-colored wire for negative. In a cable with
white and black wires, the white is positive (70V or 100V) and
the black is negative (COM). Cable with both wires the same
