10 Introduction PS-20 Power Supply
Specifications
General
Input Voltage:
100 to 240 VAC, 50 to 60 Hz
Output Voltage:
28 VDC to 32 VDC
Output Current:
1.80 Amps Maximum per channel
Termination Impedance:
Selectable 200
Ripple:
< 0.2 V
Program Input Levels:
Nominal +2 dBu
Balanced, High Impedance >10 k
Two-Wire Output Levels:
Nominal 30 VDC
Unbalanced, selectable 200
Monitor Output:
Nominal Gain of 0 dB for 1000 mV
RMS input
level on the program input. 30 VDC nominal, 100
mA maximum.
Audio Link
Nominal input 2 dBu with a Gain of 0 dB
Connections
Type: 3-pin XLR male (RTS 2-channel Mode)
Pin 1 Common for Audio and DC
Pin 2 30 VDC and Mixed Audio Channel 1
Pin 3 30 VDC and Mixed Audio Channel 2
Type: 3-pin XLR male (RTS 4-channel Mode)
Pin 1 Common for Audio and DC
Pin 2 30 VDC and Mixed Audio Channel 1 or
3
Pin 3 Mixed Audio Channel 2 or 4
Type: 3-pin XLR male (Clear-Com Mode)
Pin 1 Common for Audio
Pin 2 30 VDC
Pin 3 Mixed Audio Channel 1 or 2
Program Input
Type: 3-pin XLR female
Pin 1 Common
Pin 2 Balanced Audio + Input
Pin 3 Balanced Audio - Input
Audio Link
Input 1/4” Stereo Phono Jack
Tip: Channel 1
Ring: Channel 2
Sleeve: Ground
Output 1/4” Stereo Phono Jack
Tip: Channel 3
Ring: Channel 4
Sleeve: Ground
AC Input
Type: Universal AC Plug
Pin 1 Hot
Pin 2 Neutral
Pin 3 Earth Ground
Monitor Output
Type: 3-pin XLR male (RTS 2-channel Mode)
Pin 1 Common for Audio and DC
Pin 2 30 VDC and Mixed Audio Channel 1
Pin 3 30 VDC and Mixed Audio Channel 2
Type: 3-pin XLR male (RTS 4-channel Mode)
Pin 1 Common for Audio and DC
Pin 2 30 VDC and Mixed Audio Channel 1
Pin 3 Mixed Audio Channel 2
Type: 3-pin XLR male (Clear-Com Mode)
Pin 1 Common for Audio
Pin 2 30 VDC
Pin 3 Mixed Audio Channel 1
Environmental
Operating Temperature
0° C - 50° C (32° F to 122 ° F)
Storage
-40° C to 70° C (-40° F to 158° F)
Humidity
0 to 95%, non-condensing
Dimensions and Finish
Height
1.72 inches (44 mm) - 1 RU
Width
8.186 inches (207.9 mm)
Weight
Under 5lbs.
Finish
Thermoplastic front panel, Aluminum case, RTS
light gray paint - black silk screen.
Mounting - MCP Style rack kit or (included rubber
adhesive feet).
Approvals and Listings
CE (Comformité Européenne)
UL (Underwriters Laboratory)
CSA (Canadian Standards Associations)
WEEE (Waste Electrical and Electronics
Equipment)
ROHS (Restriction of Hazardous Substances)
