10 Introduction KP-3016/KP-3016A Series
Specifications
LCD Display
KP-3016/3016A:
Active Area.................. 120.10mm (wide) x 18.77mm (high)
Dot Resolution............................................... 576 x 90 pixels
Color Resolution.............................. 16-bit (64K) RGB color
View Angle ...................... 80 degrees (typical; all directions)
Power Supply:
Type: .....................................................................External DC
AC Input: .............................................100–240VAC 50/60Hz
Inputs:
Matrix
Type ...........................................................................Balanced
Typical Input Level........................................................+8dBu
Typical Input Impedance .............................................. >10kΩ
Maximum Input Level .................................................+20dBu
Supported Bandwidth .................................... 100Hz to 20kHz
Panel Mic
Type ............................................................................. Electret
Typical Input Level.......................................................-42dBu
Typical Input Impedance ................................................1.0kΩ
Maximum Input Level ..................................................-25dBu
Headset Mic - Electret
Typical Input Level.......................................................-42dBu
Typical Input Impedance ................................................1.0kΩ
Maximum Input Level ..................................................-25dBu
Headset Mic - Dynamic
Typical Input Level.......................................................-50dBu
Typical Input Impedance .................................................600Ω
Maximum Input Level ..................................................-25dBu
Outputs:
Matrix
Type ...........................................................................Balanced
Typical Output Level .....................................................+8dBu
THD+N%..................................................................... <0.20%
Typical Output Impedance...............................................600Ω
Maximum Output Level ..............................................+20dBu
Frequency Response ...................................... 100Hz to 20kHz
Headset
Maximum
Output Power......................................... 125mW for 32Ω load
Earphone Impedance ........................................16Ω and above
THD+N% .....................................................................<0.20%
Frequency Response.......................................100Hz to 20kHz
Speaker
SPL..........................84dBSPL for 1kHz sine wave @ 1 meter
Digital (KP-3016 Only):
OMNEO Channels
Typical OMNEO Latency .............................................. 1.0ms
Frequency Response.......................................... 20Hz - 20kHz
NOTE: The Playout Delay and Bandwidth depend on the
configured amount of audio per packet.
Environmental:
Dimensions
KP-3016
17.39” W (without rack ears) x 1.72” H x 3.88” D
(441.82mm x 43.8mm x 98.5mm
[111.11mm including volume knobs and lever keys])
KP-3016A
17.39” W (without rack ears) x 1.72” H x 3.88” D
(441.82mm x 43.8mm x 98.5mm
[111.11mm including volume knobs and lever keys])
Weight
KP-3016 ......................................................... 3.35 lb (1.52kg)
KP-3016A....................................................... 3.35 lb (1.52kg)
Power Supply ................................................. 0.53lb (0.24kg)
Power Supply
Mounting Bracket......................................... 0.30lb (0.14kg)
Temperature
Operating................................... 0°C to 55°C (32°F to 131°F)
Storage..................................... -20°C to 70°C (-4°F to 158°F)
Compression
Bit Rate
Coding Delay
Playout Delay
Bandwidth
Sample Rate
G.711 64 kbps 125 µs 20-60 ms 160-224 kbps 8 k
G.729AB 8 kbps 10 µs 20-120 ms 32-112 kbps 8 k
G.722 64 kbps 4 µs 20-60 ms 160-224 kbps 16 k
* Data rate depends on codec selection
