28 Installation KP Series
Address Setting
General Information
In ADAM intercoms using AIO-8 cards or AIO-16 cards with SCSI breakouts, and in ADAM-CS and Zeus/Zeus II intercoms,
the intercom ports share data connections in groups of eight. Each keypanel is uniquely identified on the data port by its
address. The method of determining the proper address varies for each intercom system. Use the method for your intercom
system, as described on the following pages.
To see specific addressing information for:
• ADAM with AIO-8 cards, see the ADAM technical manual (P/N F01U216986)
• ADAM CS, see the ADAM CS technical manual (P/N 93307517000)
• ADAM and ADAM-M with AIO-16 cards, see the AIO-16 user manual (P/N F01U193267)
• Cronus, see Cronus user manual (P/N F01U118890)
• Zeus III, see the Zeus III user manual (P/N F01U193289)
• Zeus III LE/LE+, see the Zeus III LE/LE+ user manual (P/N F01U193290)
NOTE: If you are connecting to an ADAM or ADAM-M frame with AIO-16 cards using MDR connectors or a Cronus
frame, you do not need to set the address. If the AIO-16 is using SCSI breakouts, you must set the address.
TABLE 1. KP-Series Addressing
Manually Addressed Automatically Addressed
You must manually address
a
the keypanel when using the
following
:
• AIO-8 on ADAM
• AIO-16 SCSI on ADAM
• ADAM CS
a. To manually address the KP-5032/4016, see “Service Menu, Set Address” on page 255.
The keypanel address is automatically detected when using
the following:
• AIO-16 MDR on ADAM and ADAM-M
• Cronus
• Zeus III and Zeus III LE/LE+
• RVON Products - RVON-8, RVON-2,
RVON-C, and RVON-16
NOTE: Keypanels using RVON-I/O may need to be
individually addressed. See the RVON-I/O user
manual for further instruction.
