14 Introduction KP Series
Specifications
LCD Display
KP-4016:
Active Area................ 120.10 mm (wide) x 18.77 mm (high)
Dot Resolution................................................576 x 90 pixels
Color Resolution .............................16-bit (64 K) RGB color
View Angle.......................80 degrees (typical; all directions)
KP-5032
Active Area ................. 120.10 mm (wide) x 35.86 mm (high)
Dot Resolution................................................576 x 172 pixels
Color Resolution ...............................16-bit (64 K) RGB color
View Angle........................ 80 degrees (typical; all directions)
Power Supply:
Type:..................................................................... External DC
AC Input:........................................... 100–240 VAC 50/60 Hz
General Purpose Inputs and Outputs:
Outputs
Type (relays)................................................................... SPDT
Contact Rating............................................1 AMP @ 30 VDC
Inputs
Type.............................................................Optically Coupled
Input Voltage ................................................ 5-18 VDC on A+
A+ is internally pulled to 5VDC. Connect K- to to activate.
Inputs:
Matrix
Type........................................................................... Balanced
Typical Input Level ...................................................... +8 dBu
Typical Input Impedance ..............................................>10 kΩ
Maximum Input Level................................................ +20 dBu
Supported Bandwidth...................................100 Hz to 20 kHz
Aux 1 and Aux 2
Type........................................................................... Balanced
Typical Input Level ...................................................... +8 dBu
Typical Input Impedance ..............................................>10 kΩ
Front Panel Mic
Type ............................................................................. Electret
Typical Input Level......................................................-42 dBu
Typical Input Impedance ..................................................1 kΩ
Maximum Input Level .................................................-25 dBu
Rear Panel Mic
Type ............................................................................. Electret
Typical Input Level......................................................-42 dBu
Typical Input Impedance ..................................................1 kΩ
Maximum Input Level .................................................-25 dBu
Front and Rear Headset Mic - Electret
Typical Input Level......................................................-42 dBu
Typical Input Impedance ..................................................1 kΩ
Maximum Input Level .................................................-25 dBu
Front and Rear Headset Mic - Dynamic
Typical Input Level......................................................-50 dBu
Typical Input Impedance ................................................600 Ω
Maximum Input Level .................................................-25 dBu
Outputs:
Matrix
Type ...........................................................................Balanced
Typical Output Level ....................................................+8 dBu
THD+N%..................................................................... <0.20%
Typical Output Impedance..............................................600 Ω
Maximum Output Level .............................................+20 dBu
Frequency Response .................................... 100 Hz to 20 kHz
MIC/LINE Out
Type ...........................................................................Balanced
Typical Output Level ....................................................+8 dBu
THD+N%..................................................................... <0.20%
Typical Output Impedance..............................................600 Ω
Maximum Output Level .............................................+20 dBu
Frequency Response .................................... 100 Hz to 20 kHz
