RCLK-W600 model
1. Close device doors.
2. The device will start automatically once connected to
a power source.
The device will start refrigerating to the set temperature
and will regularly run a defrost a few times a day depending
on controller settings (usually every 4 hours).
DEFROSTING
AUTOMATIC DEFROST:
The device shall require a defrost if internal ice build-up
occurs. This may happen due to too frequent opening
of the doors for long periods. The device automatically
activates its auto defrost cycle every four hours. To
manually activate defrost:
MANUAL DEFROST
Press and hold down the button for at least 5 seconds
– defrost will start and an appropriate message will appear
in the display. Defrost takes a maximum of 30 minutes.
ATTENTION: Manual defrost resets the automatic defrost
schedule. The next automatic defrost will start 4 hours after
manual defrost ends.
ATTENTION! Do not use electrical devices (such as a hair
dryer) or open re to defrost the device. Plastic elements
of the interior may melt and a spark or ame may ignite
the fumes. The device oor includes an opening with a cap
used to discharge larger quantities water outside of the
device. Wipe dry small quantities of condensed water with
a soft cloth or sponge.
DOOR LOCK
To prevent unauthorized opening the device doors may be
locked.
DEVICE CONTROLLER OPERATION:
SWITCHING THE DEVICE ON
Models RCGK-W200, RCKG-W400, RCLK-F590-G, RCLK-
F590GB, RCLK-F380G, RCLK-F380GB, RCLK-C590GB
1. Close the appliance door
2. Make sure that the backlight on/o button is set to
“O” and plug the appliance power cord into a mains
outlet.
3. The appliance will start. See the control panel
settings further in this manual.
4. You can turn the appliance backlight on and o with
the backlight on/o button
Displaying settings. In service
programming mode – select
parameter and conform
changes.
Start manual defrost.
Scroll list of parameters (in
service programming mode)/
Increase set value
Scroll list of parameters (in
service programming mode)/
Decrease set value
BUTTON COMBINATIONS
Lock/unlock buttons
EN
CLEANING AND MAINTENANCE
It is recommended to wash the appliance regularly. Before
start of cleaning of the appliance or before performance
of any repair or maintenance work, it is necessary to
disconnect the appliance from the power supply and
wait until it has cooled down. Do not use for washing any
caustic cleaners, such as cleaning powders, agents with
alcohol content, thinners, diluents, etc., and do not allow
water to enter the appliance interior. Never immerse the
appliance, cord or plug in water or any other liquid. It is
forbidden to clean the device with a water jet. The interior
of the device should be cleaned with a disinfectant suitable
for the food industry. To clean, use a damp, soft cloth and
then dry thoroughly. Dry the surface with a soft, dry cloth.
The following actions should be taken if the machine is not
used for a long period of time: Disconnect the appliance
completely from the power supply and remove all food
products from it. Then wash the entire appliance with
a damp, soft cloth and mild cleaning agent, rinse with clean
water and dry thoroughly, for some time leave the door
open, so that the appliance will be completely dry. From
time to time, check that the cable is not damaged. Do not
use the appliance if the cable is damaged. A damaged cable
must be replaced by a service or a qualied electrician. In
the event of damage or malfunction, please contact your
dealer or our service. Maintenance and repair work must
be done only by qualied personnel using original spare
parts and accessories. Attempts to make repairs on your
own can lead to a direct threat to life or health, and will
void the warranty!
CHECK REGULARLY THE DEVICE
Check regularly that the device doesn t present any
damage. If there is any damage, please stop using the
device. Please contact your customer service to solve the
problem.
What to do in case of a problem?
Please contact your customer service and prepare following
information:
• Invoice number and serial number (the latter is to be
found on the technical plate on the device).
• If relevant, a picture of the damaged, broken or
defective part.
• It will be easier for your customer service clerk to
determine the source of the problem if you give
a detailed and precise description of the matter.
The more detailed your information, the better the
customer service will be able to answer your problem
rapidly and eciently!
CAUTION: Never open the device without the authorization
of your customer service. This can lead to a loss of warranty!
TROUBLESHOOTING
Initiate service programming
mode – ATTENTION! IT IS
RECOMMENDED NOT TO
INITIATE THE SERVICE MODE –
all the factory parameters were
set in this mode and changes
may result in incorrect device
operation.
Return to ambient temperature
display.
SYMBOL MODE DESCRIPTION
ON Compressor is active
Flashing Prevention of short operation
periods activated
ON Active defrosting
Flashing Active dripping
ON Fan ON
Flashing Delayed ventilator activation
after defrosting
ON Unit of temperature
Flashing Programming mode
ON Unit of temperature
Flashing Programming mode
DISPLAYING SETTINGS
1. Briey press the SET button and the current setting
will be displayed.
2. To return to the standard screen briey press SET or
wait for approximately 5 seconds.
CHANGING SETTINGS
1. Press and hold down the SET button for
approximately 3 seconds
2. The current setting will be displayed and °C or °F
diode will ash.
3. Change the setting using or .
4. To accept changes press the SET button.
LOCKING BUTTONS
Press and hold down the and buttons for at
least 3 seconds. „OF“ will be displayed – the buttons are
now locked.
UNLOCKING BUTTONS
Press and hold down the and buttons for at
least 3 seconds. „on“ will be displayed – the buttons are
now active.
TRANSPORTATION AND STORAGE
During transport, the machine should be protected from
shaking, falling and turning upside down. Store it in
a properly ventilated place with dry air and without any
corrosive gas.
Problem Probable cause Action
The
appliance
is not
working
The unit is not
switched on
Check the unit
is plugged in
correctly and
switched on
Plug and lead are
damaged
Call your agent
or qualied tech-
nician
Fuse in the plug has
blown
Replace the fuse
EN
CAUTION! Correct connection of the device to the single
socket with earth is the guarantee of proper work. In the
case of inappropriate installation, the machine may cause
injury. Place the appliance on a at, stable surface that will
withstand its weight together with its contents. In order to
provide adequate ventilation, keep at least 20 cm of space
between the appliance and the wall or other objects. Poor
ventilation caused by insucient space around the device
may adversely impact the refrigeration process and reduce
fridge lifetime.
First start up.
1. Unpack the whole appliance.
2. Make sure that no packing material has been left in
the compressor chamber.
3. Remove all documents and other accessories from
the inside of the appliance.
4. Install all additional components of the appliance.
5. Set the height and level the device.
6. Clean and dry the interior
7. Close the door of the appliance.
8. Connect the appliance plug to the socket.
9. Set refrigeration according to requirements.
10. Load the device once the pre-set temperature has
been reached.
Height adjustment / levelling:
In order to adjust the height or level of the chiller, it is
necessary to unscrew or screw in the feet of the appliance.
FITTING SHELVES
1. Align one set of shelf brackets on each side of the
interior at the required height.
2. Slide shelf into place
3. Repeat for the remaining shelves.
Shelf malignant is signicant for correct water drainage
Assembling the outside panel:
Attach the outside panel to the lower part of the device,
under the doors as shown on the diagram below:
15
Rev. 05.04.2022
14
Rev. 05.04.2022
