GENERAL HINTS FOR THE USER
The appliance must be cleaned after unpacking and before
its connection to the power supply network Once the
appliance has reached the set temperature, it can be lled.
It is forbidden to ll the appliance with warm liquids and
food and any food products put into the appliance should
be covered. Food products and drinks should be stored in
sealed airtight containers. In order to ensure adequate air
circulation inside the appliance it is recommended to place
products be in such a manner in order to maintain distance
between them. If the door is opened too often, there is
increased energy consumption, which could lead to possible
damage. Maximum loading of a single shelf: 30 kg. Always
close the door of the appliance when it is not in use. Do not
use screwdrivers or other metal tools in order to remove ice
layers that are formed on the walls of the appliance during
its use. In case of you do not use the appliance for a longer
time, in order to save electricity, it is necessary to disconnect
the cleaned appliance from the electricity, to clean and leave
the door open in order to prevent gathering of unpleasant
odours inside the appliance.
RCGK-W400, RCLK-F590-G,
RCLK-F590GB, RCLK-F380G,
RCLK-F380GB, RCLK-C590GB
1 3
2
4
5
4
5
1 3
2
6 6
1. Backlight on/o button
2. Lock
3. Control panel
4. Glass door
5. Schelves
6. Adjustable feet
1 2
3
4
1. Lock
2. Control panel
3. Door
4. Adjustable feet
SCOPE OF THE APPLICATION
The chillers are designed for refrigerating and storing food.
The freezers are intended for freezing and frozen storage
of food.
The user is liable for any damage resulting from
nonintended use of the device!
BERORE THE FIRST USE
Upon receipt of the goods, check the packaging for
defects and open the packaging if there are no damages.
If the packaging is damaged, please contact your transport
company and distributor within 3 days, and document the
damages as detailed as possible. Do not turn the package
upside down! When transporting the package, please
ensure that it is kept horizontal and stable.
DISPOSING OF THE PACKAGING
Please keep all packaging materials (cardboard, plastic tapes
and Styrofoam), so that in case of a problem, the device can
be sent back to the service centre in accurate condition!
Electric shock
protection class
I
AEC (Annual Energy
Consumption)
[kWh/Year]
2260 1816 2237
Climate class 4
Weight [kg] 105 89 102
Dimensions [mm] 775x723
x1850
595x653
x1850
595x635
x1850
Height adjustment Yes
Basket/shelves 7 shelves
Lock Yes
Product name Freezer
Model RCLK-
F380GB
RCLK-
F380
RCLK-
F170S
Rated input power
[W]
425 215
Rated current [A] - 2,6 2
Power consumption
[kWh/24h]
- 4,9 -
Energy class C D -
Power supply [V]/
Frequency [Hz]
230~/50
Refrigerant R290 / 120g R600a/
65g
Temperature [°C] -13÷-21 -22÷-18 -20÷-18
Net volume [l] - 206 -
Gross volume [l] 380 170
Electric shock
protection class
I
AEC (Annual Energy
Consumption)
[kWh/Year]
2237 1816 -
Climate class 4
Weight [kg] 101 85 46
Dimensions [mm] 595x635 x1850 595x653
x880
Height adjustment Yes
Basket/shelves 7 shelves 3 shelves
Lock Yes
Product name Chiller
Model RCLK-
C590GB
RCLK-
C590
RCLK-
C380GB
Rated input power
[W]
228 215
Rated current [A] -
Power consumption
[kWh/24h]
-
Energy class B D B
Power supply [V]/
Frequency [Hz]
230~/50
Refrigerant R600a/145g R600a/
100g
Temperature [°C] 0÷5 0÷8 0÷5
Net volume [l] - 376 -
Gross volume [l] 590 380
Electric shock
protection class
I
AEC (Annual Energy
Consumption)
[kWh/Year]
1296 896 1071
Climate class 4
Weight [kg] 95 89 78
Dimensions [mm] 775x705
x1850
775x723
x1850
595x635
x1850
Height adjustment Yes
Basket/shelves 4 shelves
Lock Yes
Product name Chiller
Model RCLK-C380G RCLK-C170
Rated input power
[W]
215 187
Rated current [A] - 1,4
Power consumption
[kWh/24h]
- -
Energy class D -
Power supply [V]/
Frequency [Hz]
230~/50
Refrigerant R600a/ 100g R600a/ 54g
Temperature [°C] 0÷8 0÷8
Net volume [l] 239 -
Gross volume [l] 380 170
Electric shock
protection class
I
AEC (Annual Energy
Consumption)
[kWh/Year]
603 -
Climate class 4
Weight [kg] 75 43
Dimensions [mm] 595x635 x1850 595x653 x880
Height adjustment Ja
Basket/shelves 4 shelves 3 shelves
Lock Ja
DEVICE DESCRIPTION
RCGK-W200
RCLK-W600, RCLK-F590S, RCLK-F590, RCLK-F380S,
RCLK-F380, RCLK-F170S, RCLK-C590, RCLK-C380G,
RCLK-C170
All models come with two wheels in the rear part of the
device to facilitate moving to another position.
INSTALLATION AND ASSEMBLY OF THE APPLIANCE
Always carry and transport the device in an upright
position. Grab by the base. If the device was stored or
transported in a position other than its working position,
before use stand the device in the correct position for 12h.
If there are any doubts, let it stand for the required period
of time.
EN EN
13
Rev. 05.04.2022
12
Rev. 05.04.2022
