USER MANUAL
9
EN
Rev. 19.04.2022
Parameter
description
Parameter value
Product name
GAS
GRIDDLE,
HALF-
RIBBED
GAS
GRIDDLE,
SMOOTH
GAS
GRIDDLE,
HALF-
RIBBED
Model
RC-
GGHR750
RC-
GGF750
RC-
GGHR600
Grill plate
dimensions
[mm]
745x400 745x400 600x400
Gas device
category
I2H
(20)
I2E
(20)
I2H
(20)
I2E
(20)
I2H
(20)
I2E
(20)
Number of
burners
2
Heat delivered
(kW/h)
3,1x2
Type of gas G20
Input pressure
(mbar)
20
Nozzle
diameter [mm]
1,3
Dimensions
[Width x
Depth x
Height; mm]
800x600
x370
800x600
x320
650x595
x360
Weight [kg] 40 41 31,5
Product name
GAS
GRIDDLE,
SMOOTH
GAS GRILL GAS GRILL
Model
RC-
GGF600
RC-
GG35050
RC-
-GG35030
Grill plate
dimensions
[mm]
600x400 350x400 350x400
Gas device
category
I2H
(20)
I2E
(20)
I3B/P (50)
I3
+ (28~30/
37)
Number of
burners
2 1
Heat delivered
(kW/h)
3,1x2 3,0x1
Type of gas G20 G30 G30/G31
Input pressure
(mbar)
20 50 28-30/37
Nozzle
diameter [mm]
1,3 0,78 0,9
Dimensions
[Width x
Depth x
Height; mm]
650x590
x320
400x570
x365
400x570
x365
Product name GAS GRILL
Model RC-GG35020
Grill plate
dimensions [mm]
350x400
Gas device
category
I2H(20) I2E(20)
Number of
burners
1
Heat delivered
(kW/h)
3,1x1
Type of gas G20
Input pressure
(mbar)
20
Nozzle diameter
[mm]
1,3
Dimensions
[Width x Depth
x Height; mm]
400x570x365
Weight [kg] 21,60
Gas device category
Intended for the following
countries:
I3+(28~30/37)
BE, CH, CY, CZ, ES, FR, GB, GR,
IE, IT, LT, LU, LV, PT, SI, SK, TR
I3B/P(50) AT, CH, CZ, DE, LU, SK
I2H(20)
AT, BG, CH, CY, CZ, DK, EE, ES,
FI, FR, GB, GR, HR, IE, IT, LT, LV,
NO, PT, RO, SE, SI, SK, TR
I2E(20) DE, LU, PL, RO
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
EN
8
Rev. 19.04.2022
LEGEND
The product satises the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation. (general
warning sign)
ATTENTION! Hot surface, risk of burns!
Wear protective gloves.
ATTENTION! Fire hazard - ammable
materials!
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
The original operation manual is written in German. Other
language versions are translations from the German.
2.1. SAFETY IN THE WORKPLACE
a) Make sure the workplace is clean and well lit. A messy
or poorly lit workplace may lead to accidents. Try
to think ahead, observe what is going on and use
common sense when working with the device.
b) Do not use the device in a potentially explosive
environment, for example in the presence of
ammable liquids, gases or dust. The device generates
sparks which may ignite dust or fumes.
c) If you discover damage or irregular operation,
immediately switch the device o and report it to a
supervisor without delay.
d) If there are any doubts as to the correct operation
of the device, contact the manufacturer‘s support
service.
e) Only the manufacturer‘s service point may repair the
device. Do not attempt any repairs independently!
f) Children or unauthorised persons are forbidden to
enter a work station. (A distraction may result in loss
of control over the device).
g) Use the device in a well-ventilated space.
h) Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
i) Please keep this manual available for future reference.
If this device is passed on to a third party, the manual
must be passed on with it.
j) Keep packaging elements and small assembly parts in
a place not available to children.
k) Keep the device away from children and animals.
l) If this device is used together with another equipment,
the remaining instructions for use shall also be
followed.
The terms „device“ or „product“ are used in the warnings
and instructions to refer to GAS GRIDDLE, HALF-RIBBED;
GAS GRIDDLE, SMOOTH; GAS GRILL.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
death.
REMEMBER! When using the device, protect
children and other bystanders.
2.2. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience
and/or knowledge unless they are supervised by
a person responsible for their safety or they have
received instruction on how to operate the device.
c) The device can be handled only by physically t
persons who are capable of handling it, properly
trained, familiar with this manual and trained within
the scope of occupational health and safety.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) Use personal protective equipment as required
for working with the device, specied in section 1
(Legend).
The use of correct and approved personal protective
equipment reduces the risk of injury.
f) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
g) The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
2.3. SAFE DEVICE USE
a) Do not overload the device. Use the appropriate
tools for the given task. A correctly-selected device
will perform the task for which it was designed better
and in a safer manner.
b) Disconnect the device from the power supply
before commencement of adjustment, cleaning and
maintenance. Such a preventive measure reduces
the risk of accidental activation.
c) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
d) Keep the device in perfect technical condition.
Before each use check for general damage and
especially check for cracked parts or elements and
for any other conditions which may impact the safe
operation of the device. If damage is discovered,
hand over the device for repair before use.
e) Keep the device out of the reach of children.
f) Device repair or maintenance should be carried out
by qualied persons, only using original spare parts.
This will ensure safe use.
g) To ensure the operational integrity of the device, do
not remove factory-tted guards and do not loosen
any screws.
h) When transporting and handling the device between
the warehouse and the destination, observe the
occupational health and safety principles for manual
transport operations which apply in the country
where the device will be used.
i) Do not move, adjust or rotate the device in the
course of work.
Weight [kg] 34,5 21,3 22
