3. USE GUIDELINES
The product is intended for rolling and cutting only pasta
dough. The product is intended for commercial use.
The user is liable for any damage resulting from
unintended use of the device.
1. Feeder
2. Cover I
3. Drive cover
4. Roller adjustment knob
5. Knives adjustment knob
6. Knife presser / knife presser knob
7. Cover II
8. Protective cover
9. Roller scraper
10. Transmission cover
11. Knife presser II
12. Knife scraper
13. Rear cover
14. Front panel block I
15. Pasta roller I
16. Pasta roller II
17. Engine
18. Front panel block II
19. Frame I
20. Reduction gear
21. Connecting transmission
22. Belt
23. Small pulley
24. Bearing
25. Bearing cover
26. Knife with a zipper
27. Knife gear I
28. Rama II
29. Shaft gear I
30. Mounting the drive transmission
31. Transmission I
32. Knife gear II
33. Spring
34. Shaft gear II
35. Transmission gear
36. Drive gear axle
37. Transmission II
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device is
being used. There should be at least 10 cm distance between
each side of the device and the wall or other objects. The
device should always be used when positioned on an even,
stable, clean, reproof and dry surface, and be out of the
reach of children and persons with limited mental and
sensory functions. Position the device such that you always
have access to the power plug. The power cord connected to
the appliance must be properly grounded and correspond
to the technical details on the product label.
After removing from the box, attach the feeder to it. Before
the rst use, clean the device with a soft, dry cloth. To clean
the shaft and knife, pass a piece of dough through the rollers
several times. The cake used for cleaning should be thrown
away.
3.3. DEVICE USE
1. Insert the plug into an electrical outlet.
2. The dough is rolled in the machine after the knives
are removed. To remove them, loosen the presser
adjustment knobs (6) and remove the knife pressers.
Then carefully remove the knives.
EN
9
1
3
4
2
5
6
12
11
10
9
8
7
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
32
31
30
29
28
33
34
35
36
37
e) Only the manufacturer‘s service point may repair the
device. Do not attempt any repairs independently!
f) In case of re, use a powder or carbon dioxide
(CO
2
) re extinguisher (one intended for use on live
electrical devices) to put it out.
g) Children or unauthorised persons are forbidden to
enter a work station. (A distraction may result in loss
of control over the device).
h) Please keep this manual available for future reference.
If this device is passed on to a third party, the manual
must be passed on with it.
i) Keep packaging elements and small assembly parts in
a place not available to children.
j) Keep the device away from children and animals.
EN
8
2.3. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The machine may be operated by physically t
persons who are able to handle the machine, are
properly trained, who have reviewed this operating
manual and have received training in occupational
health and safety.
c) The machine is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience and/
or knowledge unless they are supervised by a person
responsible for their safety or they have received
instruction on how to operate the machine.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
f) Do not overestimate your abilities. When using the
device, keep your balance and remain stable at all
times. This will ensure better control over the device
in unexpected situations.
g) Do not wear loose clothing or jewellery. Keep hair,
clothes and gloves away from moving parts. Loose
clothing, jewellery or long hair may get caught in
moving parts.
h) Remove all adjusting tools or spanners before turning
the device on. A tool or spanner left in the revolving
part of the device may cause injury.
i) The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
j) Do not put your hands or other items inside the
device while it is in use!
2.4. SAFE DEVICE USE
a) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
o). Devices which cannot be switched on and o
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
b) Make sure the plug is disconnected from the socket
before attempting any adjustments, accessory
replacements or before putting the device aside.
Such precautions will reduce the risk of accidentally
activating the device.
c) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
d) Keep the device in perfect technical condition. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of
the device. If damage is discovered, hand over the
device for repair before use.
e) Keep the device out of the reach of children.
f) Device repair or maintenance should be carried out by
qualied persons, only using original spare parts. This
will ensure safe use.
g) To ensure the operational integrity of the device, do
not remove factory-tted guards and do not loosen
any screws.
h) When transporting and handling the device between
the warehouse and the destination, observe the
occupational health and safety principles for manual
transport operations which apply in the country where
the device will be used.
i) Avoid situations where the device stops working
during use due to excessive loading. This may result
in overheating of the drive elements and damage to
the device.
j) Do not touch articulated parts or accessories unless
the device has been disconnected from the power
source.
k) Do not move, adjust or rotate the device in the course
of work.
l) Do not leave this appliance unattended while it is in
use.
m) Clean the device regularly to prevent stubborn grime
from accumulating.
n) The device is not a toy. Cleaning and maintenance may
not be carried out by children without supervision by
an adult person.
o) It is forbidden to interfere with the structure of
the device in order to change its parameters or
construction.
p) Keep the device away from sources of re and heat.
q) Do not overload the device.
r) Do not cover the ventilation openings!
REMEMBER! When using the device, protect children
and other bystanders.
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
3.1. DEVICE DESCRIPTION
