ENGLISH 17

2 Technical Data

Part number .............................................

FF35148 (Typ C), FF35148Z (Typ J)

Voltage ....................................................

220-240V

Frequency ...............................................

50/ 60 Hz

Rated power ............................................

1200 W

Max. power ..............................................

1400 W

Air flow at the fan .....................................

220 m³/h/MG

Negative pressure at the fan ....................

248 hPa/MG

Air flow at the hose ..................................

140 m³/h/SE

Negative pressure at the hose .................

225 hPa/SE

Connecting cable .....................................

H05VV F 3 x 1,5

Dimensions (L x W x H) ...........................

45,7 x 40 x 54 cm

Weight .....................................................

12,7 kg

Protection class ......................................

Type of protection ...................................

IP 24

Noise pressure level (L

) .......................

69,5 dB (A) ¦ K

3 dB (A)

Sound power level (L

) .........................

80,5 dB (A) ¦ K

3 dB (A)

The noise level during operation can exceed 85 dB (A). Wear hearing protection!

Measured values determined in accordance with EN 60335.

Vibration total value .............................................................

≤ 2,5 m/s

¦ K= 1,5m/s

The vibration level given in this information sheet has been measured in accordance with a

standardised test given in EN 60335 and may be used to compare one tool with another. It may

be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main applications of the tool.

However if the tool is used for different applications, with different accessories or

insertion tools or is poorly maintained, the vibration emission may differ. This may

significantly increase the exposure level over the total working period.

An estimation of the level of exposure to vibration should also take into account the

times when the tool is switched off or when it is running but not actually doing the

job. This may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibra-

tion such as: maintain the tool and the accessories, keep the hands warm, organisa-

tion of work patterns.

3 Function of the Unit

3.1 Overview (A)

Top section

Latch

Wheels

Functional plate

Lock

Steering castors

Rotary switch ON/

OFF/Automatic/Vibration

Connecting line

Filter cassettes

Motor protecion filter

Power socket for electric

tools

Container

Paper filter bag

(optional accessory)

Volume flow display (Fill

level indicator)

Suction opening

Vacuum hose

Cooling air inlet

Snap-in locks
