ENGLISH
17
2 Technical Data ROBEND 4000 E
Battery voltage ................................
............
18V
Battery capacity (recommendation)
.............
≥ 4.0 Ah
Dimensions (L x W x H, without battery)
.....
578 x 143 x 214 mm
Weight (without battery)
..............................
12,8 kg
Bending capacity ................................
........
Copper 12-35 mm/ 1/2 - 1.3/8"
stainless steel/ carbon steel 12-28 mm/ 1/2-1.1/8"
Bending angle ................................
.............
0º - 180º
Noise pressure level (L
pA
)
...........................
87 dB (A) ¦ K
pA
3 dB (A)
Sound power level (L
WA
)
.............................
100 dB (A) ¦ K
WA
3 dB (A)
The noise level during operation can exceed 85 dB (A). Wear hearing protection!
Measured values determined in accordance with EN 62841-1.
Vibration total value ................................
.............................
≤ 5,9 m/s
2
¦ K= 1,5m/s
2
The Vibration Total Value quoted in these instructions and the quoted noise emission values
were measured according to standardized measurement procedures and can be used to com-
pare one electric power tool with another. They can also be used to make an initial estimate of
the loading.
The quoted vibration and noise emissions can vary during actual use of the electric
power tool dependent on the way in which the electric power tool is used, in particular
what type of workpiece is being processed. Establish additional safety measures to
protect the operator which are based upon an estimate of the vibration loading during the actual
usage conditions (in doing so taking account of parts of the operating cycle, for example times in
which the electric power tool is switched and those in which it is switched on but not running
under load).
3 Technical Data charger and battery (D)
Battery: Charger:
U = Voltage U1 = Input voltage
C = Capacity f1 = Input frequency
W = Weight P1 = Input power
Ic = Charge current U2 = Charging voltage
t = Approx. charging time (90% full) I2 = Max. charge current
Charging voltage
.............................
20,75 V DC
Nc = No. of battery cells
Charging temperature ..
0° - 50° C, 32° - 122° F W = Weight
Max. discharging
temperature.
................................
5° - 50° C, 41° - 122° F
Pay attention to the electrical outlet
voltage! Check the label on the
bottom of the charger!
Recharge battery pack before first use!
4 Function of the Unit
Capacity: Hard and soft Cu-Al DIN 1786, DIN EN 1057/ 12735-1/ 13348 Øs 12 a 35 mm: 1,2
mm pared, Hard and soft steel DIN 2391, DIN 2393, DIN 2394; Øs 12 a 28 mm x 2,5, Steel DIN
2440 1/4” (14), 3/8” (18), 1/2 “ (22), 3/4 “ (28), INOX AISI 304-316 espesor hasta 1,5 mm Øs 12
a 28 mm.
4.1 Overview (A)
1 Battery 6 Former
2 Reverse lever 8 Former fastening shaft
3 Handle 9 Slide
4 Bolt housing 10 Slide fastening bolt
5 Tripod 11 Series bending scale
