Menus and settings

* See Menu Display and Operation (p. 30) for menu operations.

100–162 Input Parameter

* The values enclosed in a [box] are the factory defaults.

Item

Number

Item Name Description and Available Settings

100 Video Source Specifies connector from which video is to be input.

[i.LINK]: Selects the i.LINK connector.

COMPONENT: Selects the COMPONENT IN connector.

DVI-D: Selects the DVI (Digital) connector.

DVI-A: Selects the DVI (Analog) connector.

SDI: Selects the HD-SDI IN connector. (VC-300HD only)

110 i.LINK IN Selects the format of the video input to the i.LINK connector.

[Auto]: Selected automatically.

480/59.94i, 576/50i, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i: Select one of these formats.

120 COMPONENT IN Selects the format of the video input to the COMPONENT INPUT connector.

[Auto]: Selected automatically.

480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i: Select one of these

formats.

122 In 480i Setup Sets the video input setup level when 480/59.94i is selected for “120: COMPONENT IN.”

[0IRE]: Selects 0IRE. (NTSC Japan/PAL)

7.5IRE: Selects 7.5IRE. (NTSC excluding Japan)

130 DVI-D IN Selects the format of the digital video (DVI-D) input to the DVI-I INPUT connector.

[Auto]: Selected automatically.

640 x 480/60, 640 x 480/75, 800 x 600/60, 800 x 600/75, 1024 x 768/60, 1024 x 768/75, 1152 x 864/75,

1280 x 768/60, 1280 x 960/60, 1280 x 1024/60, 1280 x 1024/75, 1360 x 768/60: Select one of these formats.

131 DVI-A IN Selects the format of the analog video (DVI-A) input to the DVI-I INPUT connector.

[Auto]: Selected automatically.

640 x 480/60, 640 x 480/75, 800 x 600/60, 800 x 600/75, 1024 x 768/60: Select one of these formats.

132

DVI-A AutoConfig

Automatically adjusts the analog video (DVI-A) input to the DVI-I INPUT connector.

When "Please Push [ENTER]" is displayed, press the VALUE/ENTER knob for automatic adjustment. Au-

tomatic adjustment automatically changes the values for "133: DVI-A H Position," "134: DVI-A V Position,"

"135: DVI-A Frequency," and "136: DVI-A Phase."

133 DVI-A H Position Adjusts the horizontal position of the analog video (DVI-A) input via the DVI-I INPUT connector.

-100–[0]– +100 pixel: Larger values move the image to right.

* This is automatically adjusted when "132: DVI-A AutoConfig" is used.

134 DVI-A V Position Adjusts the vertical position of the analog video (DVI-A) input via the DVI-I INPUT connector.

-100–[0]– +100 line: Larger values move the image up.

* This is automatically adjusted when "132: DVI-A AutoConfig" is used.

135 DVI-A Frequency Fine tunes the sampling frequency for the analog video (DVI-A) input via the DVI-I INPUT connector.

-100–[0]– +100 clock: May be adjusted in this range.

* This is automatically adjusted when "132: DVI-A AutoConfig" is used.

136 DVI-A Phase Fine tunes the sampling phase for the analog video (DVI-A) input via the DVI-I INPUT connector.

-100–[0]– +100: May be adjusted in this range.

* This is automatically adjusted when "132: DVI-A AutoConfig" is used.

140 SDI IN Selects the format of the video input to the HD-SDI IN connector. [Auto]: Selected automatically.

480/59.94i, 576/50i, 720/59.94p, 720/50p. 1080/59.94i, 1080/50i: Select one of these formats.

150 Audio Source Selects the input connector of the audio to be used.

[Auto]: Automatically selects the audio input corresponding to "100: Video Source."

For i.LINK: Selects the audio input to the i.LINK connector.

For COMPONENT: Selects the audio input to the AUDIO INPUT connector.

For DVI-D: Selects the audio input to the AUDIO INPUT connector.

For SDI: Selects the audio input to the HD-SDI IN connector. (VC-300HD only)

i.LINK: Selects the audio input to the i.LINK connector.

AUDIO IN: Selects the audio input to the AUDIO INPUT connector.

SDI: Selects the audio input to the HD-SDI IN connector. (VC-300HD only)

160 AUDIO IN Ch Selects the channels where Sets which channels of the audio output from the AUDIO OUTPUT connectors,

HD-SDI OUT connector, and i.LINK connector to assign the audio input to AUDIO INPUT CH1/CH2 and

CH3/CH4.

* Please also set the SDI output assignment to "450: SDI OUT Audio Ch." (VC-300HD only)

CH1/2 CH1/2: Audio output from CH1/CH2 is output to AUDIO IN connector CH1/CH2, and Audio is output from CH3/CH4 output to AUDIO IN connector CH1/CH2.

[CH1/2 CH3/4]: Audio output from CH1/CH2 is output to AUDIO IN connector CH1/CH2, and Audio is output from CH3/CH4 output to AUDIO IN connector CH3/CH4.

CH3/4 CH1/2 : Audio output from CH1/CH2 is output to AUDIO IN connector CH3/CH4, and Audio is output from CH3/CH4 output to AUDIO IN connector CH1/CH2.

CH3/4 CH3/4 : Audio output from CH1/CH2 is output to AUDIO IN connector CH3/CH4, and Audio is output from CH3/CH4 output to AUDIO IN connector CH3/CH4.
