Contents
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . 2
USING THE UNIT SAFELY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
IMPORTANT NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the AC Cord Clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting/Disconnecting the S-240P . . . . . . . . . . . . . . . . . . . 9
Connecting to an S-4000S/S-4000H . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting Via the DC OUTPUT Adapter Cable . . . . . . . . . . . . . . 10
Turning the Power On and O . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Turning the Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Turning the Power O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Checking the System Status Indicators . . . . . . . . . . . . . . . . . . . . . 11
Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connector Information: DC OUTPUT . . . . . . . . . . . . . . . . . . . . . . . 12
Specication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Checking the Included Items
The following items are included with this unit. Check to make sure that all items are present. If anything is missing, contact your dealer.
Unit Power Cord DC OUTPUT Conversion Cable
* The shape of the power cord’s plug
varies depending on the country.
Owner’s Manual
Introduction
Thank you, and congratulations on your choice of the S-240P external power supply unit.
The S-240P is designed for use with devices such as the S-4000S, S-4000H, and M-5000. Supplying the device you’re using with backup power from
the S-240P makes possible continuous uninterrupted operation in the event of sudden failure of the device’s internal power-supply circuit or if the
device’s power switch is inadvertently turned o. It prevents interruption of audio caused by power-supply trouble.
As a further measure against power-supply trouble, we recommend connecting the device you’re using and the S-240P to dierent power sources.
Connect each power plug to a separate power outlet. Using separate sources to supply power ensures that if either the S-240P or the device you’re
using loses power, system operation can continue without interruption as long as the other unit continues to receive power.
For information on devices you can connect to the S-240P, check the following Roland website.
http://proav.roland.com
