25
Setting the Input Channels
Using the Stereo Link feature lets you simultaneously manipulate two adjacent channels, one odd-numbered and one even (1
and 2, 3 and 4, 5 and 6, or 7 and 8). You use this when you’re inputting a stereo sound source to the S-0808. When Stereo Link is
on, the gain, pad, and other settings made on the odd-numbered channel are automatically copied to the even-numbered
channel.
Switching On Stereo Link
1. Select the channel.
Turn the [CHANNEL] knob to select one of the channels you want to link. If you want to link channels 3 and 4, choose [03] or [04].
2. Link the odd-numbered and even-numbered channels.
Hold down the [CLIP CLEAR/ENTER] button and turn the [CHANNEL] knob clockwise. This switches on Stereo Link.
fig.link-on.eps
3. Make sure the link is in effect.
When you release the [CLIP CLEAR/ENTER] button, two periods (“.”) appear in the channel number shown on the numerical
display.
fig.stereo-link-LED.eps
Switching Off Stereo Link
1. Select the channel.
Turn the [CHANNEL] knob to select one of the channels you want to unlink.
2. End the link.
Hold down the [CLIP CLEAR/ENTER] button and turn the [CHANNEL] knob counterclockwise. This switches off Stereo Link.
3. Make sure that the link has ended.
When you release the [CLIP CLEAR/ENTER] button, the two periods that are displayed disappear from the numerical display.
Even when Stereo Link is on, you can still switch +48 V phantom power on and off independently for individual channels.
Switching off Stereo Link does not make the values for gain, pad, and other settings go back to what they were before Stereo Link was switched
on. The values made while linked remain in effect.
Manipulating Two Channels As a Pair (Stereo Link)
When ch 7 and 8
are linked
