21
Turning the Power On and Off
2. Fasten the holder and battery plate assembled in step 1.
Using four included screws, fasten the battery plate and holder assembly to the side panel of the S-0808.
* Be careful not to overtighten, because doing so may damage the S-0808.
fig.fit-to-S0808.eps
3. Install the external battery.
Install a compatible external battery on the battery plate.
fig.fit-IDX.eps
4. Start supplying power from the external battery.
Connect the power cable to the DC IN port on the S-0808. The supply of power starts and the S-0808 is powered up. The POWER
indicator lights up when the power comes on.
fig.plug-ext-bat.eps
Turning the Power Off
Disconnecting the power cable from the S-0808’s DC IN port cuts off the power to the S-0808.
External batteries providing an output voltage between 12 V and 18 V DC are supported. Use a product within this range.
The operating time when using a fully charged ENDURA-10 (E-10) from IDX Company, Ltd. is approximately 4.5 hours.
* This is the operating time when +48 V phantom power is supplied to all INPUT channels.
* Operating times may vary depending on ambient temperature, the current consumption of the device receiving +48 V phantom power, and
other usage conditions.
* Batteries for broadcast video-cameras have a feature to display the remaining charge. Check the remaining charge before
connecting. It is possible to check the remaining charge while supply power to S-0808. It is recommended to check remaining
charge pperiodically.
About External Batteries
