19
Turning the Power On and Off
The S-0808 is compatible with the following two types of power sources.
• REAC EMBEDDED POWER When the unit is connected to an S-4000M, S-4000D, or other source device of REAC EMBEDDED POWER,
it operates with power supplied via the REAC cable.
• External battery When the unit is not connected to a source device providing REAC EMBEDDED POWER, the unit must be
powered by an external battery.
Use a battery for broadcast video cameras as the external battery.
* Once the connections have been completed , turn on power to your various devices in the order specified. By turning on devices in the wrong
order, you risk causing malfunction and/or damage to speakers and other devices.
* Always make sure to have the volume level turned down before switching on power. Even with the volume all the way down, you may still
hear some sound when the power is switched on, but this is normal, and does not indicate a malfunction.
Connecting device providing REAC EMBEDDED POWER like the S-4000M or S-4000D enables power to be supplied via the REAC
cable.
* Power is supplied from certain REAC ports of device providing REAC EMBEDDED POWER. Before making the connections, check which ports
can supply power. For information on which ports can supply power, refer to the owner’s manuals for the respective devices.
fig.power-from-S4000M.eps
Turning the Power On
1. Using a REAC cable, make the connection with the power source.
Using a REAC cable, connect the device providing REAC EMBEDDED POWER like the S-4000M or S-4000D.
* Before making the connections, switch off the power on all the devices.
2. Switch on the power on the source device.
Switch on the of source device. The POWER indicator on the S-0808 lights up, and then the REAC indicator flashes.
If any amps or speakers are connected to the REAC devices, then to prevent malfunction or damage to the speakers or other devices, always turn
down the volume, and turn off the power on all devices before making any connections.
The S-0808 may not boot up correctly if the power supply from REAC EMBEDDED POWER source device is stared while S-4000R is connected to
S-0808’s REMOTE connector. Start power from your REAC EMBEDDED POWER source device first to boot up S-0808 and then connect S-4000R,
or supply power from external battery.
Turning the Power Off
Switch off the power on the REAC EMBEDDED POWER source device. After powering down all devices, detach the REAC cable.
Using REAC EMBEDDED POWER
Audio Signal
Power
Power Source
