MC-707 Update – Functions Added in Ver.1.20
1818
Sample Browser Function Added
The sample browser now supports a folder hierarchy.
Controller Explanation
[>] button Moves to a lower folder.
[<] button Moves to the higher folder.
[ENTER] button
When a folder level is selected: Moves to a lower folder.
When a le is selected: Loads the sample.
[FUNC] button Previews the sample.
[C4] knob
(press)
IMPORT
When a folder level is selected: Moves to a lower folder.
When a le is selected: Loads the sample.
PREVIEW
Previews the sample.
AUTO PV
Automatically previews when you select a sample.
Clip Line Load Function Added
When importing clips, you can now import an entire line.
Loading clips by line
1.
In the HOME screen, select a line.
2.
Press the [CLIP] button.
The PROJECT LINE LOAD screen appears.
MEMOMEMO
¹
Select a line in which all clips are empty.
¹
The clip name for track 1 is shown.
3.
Use the cursor [ ] [ ] buttons to select the load that you
want to load, and press the [ENTER] button.
The clips are loaded.
MEMOMEMO
Loading is not possible if the track type is dierent, or if there is insucient
memory.
Looper Track Functions Added
The following functions are added to the sample waveform edit screen
(3rd page).
Ø
For details on the sample waveform edit screen, refer to “Reference
Manual” (PDF).
Controller Function Explanation
[C2] knob EXPORT
Press the [C2] knob to export the sample to the
EXPORT folder of the SD card.
[C3] knob NORMALIZE
Use the [C3] knob to specify the normalized
level, and then press the [C3] knob to execute
normalization.
MIDI Input/Output Functions Added
Knob operations, switching clips, switches scenes, MIDI output
The following items are added to the system settings (MIDI tab).
Parameter Value Explanation
Control Channel
CH1, CH2, CH3…
CH16
Species the MIDI channel that switches scenes.
Control Tx MIDI
OUT1
OFF, ON
Species whether scene changes are output to
MIDI OUT 1.
Control Tx MIDI
OUT2
OFF, ON
Species whether scene changes are output to
MIDI OUT 2.
Control Tx USB MIDI OFF, ON
Species whether scene changes are output to
USB MIDI.
Control Rx OFF, ON
Species whether scene changes are received
from an external device.
The following items are added to the track settings (MIDI tab).
Parameter Value Explanation
Tx MIDI Note OFF, ON
Species whether the notes of each track are
output.
* This is not shown for a looper track.
Tx MIDI Control
Change
OFF, ON
Species whether knob operations of each
track are output.
Tx MIDI Program
Change
OFF, ON
Species whether clip changes of each track are
output.
Pad Sensitivity Adjustment Function Added
The following item is added to the system settings (CTRL tab).
Parameter Value Explanation
Pad Gain 0–100
Adjusts the pad sensitivity. This is valid when
Pad Curve Type is LINER, EXP, or LOG.
Increasing this value increases the sensitivity,
so that the maximum velocity can be produced
more easily.
Metronome Sound Output Destination Selection Function
Added
The following item is added to the system settings.
Parameter Value Explanation
Metronome
Position
MIXOUT
Output to after the total eect.
(Output both to MIXOUT and headphones)
PHONES Output only to headphones.
ASSIGN OUT Output only to ASSIGN OUT.
PRE T-FX
Output to before the total eect.
(Output both to MIXOUT and headphones)
