5858
MFX parameter list
Chorus Ó Flanger
L out
R out
Balance D
Balance D
Balance W
Balance W
Feedback
Balance D
Balance W
Balance W
Balance D
L in
R in
Chorus Flanger
Parameter Value Explanation
Chorus Pre
Delay
0.0–100 [msec] Adjusts the delay time from when
the direct sound begins until the
chorus sound is heard.
Chorus Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Chorus Rate
(Hz)
0.05–10.00 [Hz] Modulation frequency of the chorus
eect
Chorus Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Chorus
Depth
0–127 Modulation depth of the chorus
eect
Chorus
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
Flanger Pre
Delay
0.0–100 [msec] Adjusts the delay time from when
the direct sound begins until the
anger sound is heard.
Flanger Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Flanger Rate
(Hz)
0.05–10.00 [Hz] Modulation frequency of the anger
eect
Flanger Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Parameter Value Explanation
Flanger
Depth
0–127 Modulation depth of the anger
eect
Flanger
Feedback
-98–+98 [%] Adjusts the proportion of the anger
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Flanger
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
anger (W) and the sound that is not
sent through the anger (D).
Level 0–127 Output Level
JD-Multi
Recreates the eects included in group A of the JD-800.
L out
R out
L in
R in
SpectrumDistortion Phaser Enhancer
Parameter Value Explanation
Structure Selects the connection order of the eects.
DS: Distortion, PH: Phaser, SP: Spectrum, EN: Enhancer
1 DS - PH - SP - EN
2 DS - PH - EN - SP
3 DS - SP - PH - EN
4 DS - SP - EN - PH
5 DS - EN - PH - SP
6 DS - EN - SP - PH
7 PH - DS - SP - EN
8 PH - DS - EN - SP
9 PH - SP - DS - EN
10 PH - SP - EN - DS
11 PH - EN - DS - SP
12 PH - EN - SP - DS
13 SP - DS - PH - EN
14 SP - DS - EN - PH
15 SP - PH - DS - EN
16 SP - PH - EN - DS
17 SP - EN - DS - PH
18 SP - EN - PH - DS
19 EN - DS - PH - SP
20 EN - DS - SP - PH
Parameter Value Explanation
Structure 21 EN - PH - DS - SP
22 EN - PH - SP - DS
23 EN - SP - DS - PH
24 EN - SP - PH - DS
DISTORTION OFF, ON Turns the distortion on/o.
PHASER OFF, ON Turns the phaser on/o.
SPECTRUM OFF, ON Turns the spectrum on/o.
ENHANCER OFF, ON Turns the enhancer on/o.
Distortion
Type
Sets the type of distortion.
MELLOW DRIVE Softer distortion with a slightly
darker sound.
OVERDRIVE Distortion that resembles a vacuum
tube amp being driven.
CRY DRIVE Distortion that emphasizes the high
end.
MELLOW DIST Gives the feeling of distortion
playing through a large amp.
LIGHT DIST Strong distortion with a bright
sound.
FAT DIST Thick distortion that emphasizes the
low and high ends.
FUZZ DIST Distortion that’s even more powerful
that FAT DIST.
Distortion
Drive
0–100 Sets the amount of distortion.
Distortion
Level
0–100 Sets the distortion output level.
Phaser
Manual
50–15k [Hz] Sets the basic frequency from which
the sound is modulated with the
phaser eect.
Phaser Rate 0.1–10.0 [Hz] Sets the cycle of the phaser
modulation.
Phaser Depth 0–100 Sets the depth of the phaser
modulation.
Phaser Reso 0–100 Sets the amount of feedback for the
phaser. Increasing the value creates a
more unusual sound.
Phaser Mix 0–100 Sets the level of the phase-shifted
sound.
