MFX parameter list
Overdrive Ó Delay
L out
R out
Balance W
Feedback
Balance W
Balance D
Balance D
L in
R in
DelayOverdrive
Parameter Value Explanation
Overdrive
Drive
0–127 Degree of distortion
Also changes the volume.
Overdrive
Pan
L64–63R Stereo location of the overdrive
sound
Delay Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay Time
(msec)
1–2600 [msec] Adjusts the time from the original
sound until delay sounds is heard.
Delay Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay
Feedback
-98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Delay HF
Damp
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Adjusts the frequency above which
sound fed back to the eect will be
cut. If you do not want to cut the
high frequencies, set this parameter
to BYPASS.
Delay
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
Level 0–127 Output Level
Distortion Ó Chorus
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Distortion Chorus
Parameter Value Explanation
Distortion
Drive
0–127 Degree of distortion
Also changes the volume.
Distortion
Pan
L64–63R Stereo location of the overdrive
sound
Chorus Pre
Delay
0.0–100 [msec] Adjusts the delay time from when
the direct sound begins until the
chorus sound is heard.
Chorus Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Chorus Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Chorus Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Chorus
Depth
0–127 Depth of modulation
Chorus
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
chorus (W) and the sound that is not
sent through the chorus (D).
Level 0–127 Output Level
Distortion Ó Flanger
L out
R out
Balance W
Feedback
Balance W
Balance D
Balance D
L in
R in
FlangerDistortion
Parameter Value Explanation
Distortion
Drive
0–127 Degree of distortion
Also changes the volume.
Distortion
Pan
L64–63R Stereo location of the overdrive
sound
Flanger Pre
Delay
0.0–100 [msec] Adjusts the time from the original
sound until anger sounds is heard.
Flanger Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Flanger Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Flanger Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Flanger
Depth
0–127 Depth of modulation
Flanger
Feedback
-98–+98 [%] Adjusts the proportion of the anger
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Flanger
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
anger (W) and the sound that is not
sent through the anger (D).
Level 0–127 Output Level
