MFX parameter list
Parameter Value Explanation
Delay Left
(msec)
1–1300 [msec] Adjusts the time until the left delay
sound is heard.
Delay Left
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay Right
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay Right
(msec)
1–1300 [msec] Adjusts the time until the right delay
sound is heard.
Delay Right
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Phase Left NORMAL,
INVERSE
Phase of left and right delay sound
NORMAL: Non-inverted
INVERT: Inverted
Phase Right
Feedback
Mode
NORMAL,
CROSS
Selects the way in which delay sound
is fed back into the eect. (See the
gures above.)
Feedback -98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
HF Damp 200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Adjusts the frequency above which
sound fed back to the eect is
ltered out. If you don’t want to lter
out any high frequencies, set this
parameter to BYPASS.
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Balance D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Parameter Value Explanation
Level 0–127 Output Level
Modulation Delay
Adds modulation to the delayed sound.
When Feedback Mode is NORMAL:
R out
L out
Balance W
Feedback
Feedback
Balance D
Balance D
L in
R in
Balance W
2-Band EQ
2-Band EQ
Delay Modulation
Delay Modulation
When Feedback Mode is CROSS:
R out
L out
Balance W
Feedback
Feedback
Balance D
Balance D
L in
R in
Balance W
2-Band EQ
Delay
Delay Modulation
2-Band EQ
Modulation
Parameter Value Explanation
Delay Left
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Parameter Value Explanation
Delay Left
(msec)
1–1300 [msec] Adjusts the time until the left delay
sound is heard.
Delay Left
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay Right
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay Right
(msec)
1–1300 [msec] Adjusts the time until the right delay
sound is heard.
Delay Right
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Feedback
Mode
NORMAL,
CROSS
Selects the way in which delay sound
is fed back into the eect. (See the
gures above.)
Feedback -98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
HF Damp 200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Adjusts the frequency above which
sound fed back to the eect is
ltered out. If you don’t want to lter
out any high frequencies, set this
parameter to BYPASS.
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
