Panel & Display Description
Front Panel
1. VOLUME knob
Adjust the master volume.
2. POWER SWITCH
Turn the Power on or off.
3. [SHIFT] button
Select the secondary functions of
other buttons.
10. [FADE] button
Turn the fade-in or fade-out
function on or off.
11. [CHORD] button
Enter the chord mode.
26. [DEMO] button
Enter the Demo Mode.
27. LCD Display
Display all parameters and values
related to the current operation.
28. DATA DIAL
Adjust the parameter value.
29. [-]/[+] and NUMERIC buttons
Set parameters value or select the number.
When the [SHIFT] button released
4. [TEMPO +]/[TEMPO -] button
Adjust the current Tempo.
12. [BANK] button
Select a memory bank.
13. [STORE] button
Register the panel settings.
14~17. [M1]~[M4] buttons
Recall a registered panel setting.
18. [O.T.S.] button
Turn the One Touch Setting
function on or off.
19. [HARMONY] button
Turn the Harmony effect on or off.
20. [PIANO] button
Enter the Piano Mode.
21. [METRONOME] button
Turn the metronome on or off.
22. [MIXER] button
Enter the Mixer menu.
23. [VOICE] button
Enter the Voice mode.
24. [STYLE] button
Enter the Style mode.
25. [SONG] button
Enter the Song mode.
When the [SHIFT] button pressed
4. [ACCOMP +]/[ACCOMP -]
Adjust the accompaniment volume.
12. [RECORD] button
Enter the Recording mode.
13. [PLAY] button
Play back the recording.
14. [DUAL] button
Turn the Dual function on or off.
15. [LOWER] button
Turn the Lower function on or off.
16. [DICT.] button
Enter the Chord Dictionary.
17. [DSP] button
Turn the DSP function on or off.
18. [TOUCH] button
Enter the Touch setting menu.
19. [SUSTAIN] button
Turn the Sustain function on or off.
20. [FUNCTION] button
Enter the Function menu.
21. [OCTAVE] button
Enter the Octave setting menu.
22. [TRANSPOSE] button
Enter the Transpose setting menu.
23. [L] button
Choose to practise the left hand
part in Lesson Mode.
24. [R] button
Choose to practise the right hand
part in Lesson Mode.
25. [LESSON] button
Enter the Lesson Mode.
04
1
11
2
20
12 13
14
15 16
17
18
19
5
6
7
8
9
10
4
3
21
22
24
27
26
28
36
23
25
29
In Song Mode
5. [ ] button
Start or Stop playing the song.
6. [ ] button
Pause or continue playing the song.
7. [ ] button
Set the beginning and the end for a
loop section of the current song.
8. [ ] button
Rewind the song.
9. [ ] button
Fast forward the song.
In Style Mode
5. [START/ STOP] button
Start or Stop playing the style.
6. [SYNC START] button
Turn the Sync Start on or off.
7. [INTRO/ ENDING] button
Play the Intro or Ending.
8. [FILL A] button
Play the fill-in pattern A.
9. [FILL B] button
Play the fill-in pattern B.
