USB HD Video Conference Camera User Manual
3
Vertical Rotation
Range
-30° ~ +90°
Pan Speed
Range
2.7° ~ 35.7°/s
Tilt Speed
Range
2.7° ~ 31.5°/s
H&V Flip Support
Image Freeze Support
Number of
Preset
255
Preset Accuracy 0.1°
Network Features
Video
Compression
H.264/MJPEG
Video Stream
First Stream,
Second Stream
First Stream
Resolution
1920x1080, 1280x720,
1024x576, 960x540,
640x480, 640x360
Second Stream
Resolution
1280x720, 1024x576,
720x576 (50Hz),
720x480 (60Hz),
720x408, 640x360,
480x272, 320x240,
320x180
Video Bit Rate for
First Stream
32Kbps ~ 20480Kbps
Video Bit Rate for
Second Stream
32Kbps ~ 6144Kbps
Bit Rate Control CBR, VBR
Frame Rate
50Hz: 1fps ~ 50fps,
60Hz: 1fps ~ 60fps
Audio Type AAC
Audio Bit Rate 96Kbps, 128Kbps, 256Kbps
Protocols
TCP/IP, HTTP, RTSP,
RTMP(S), ONVIF, DHCP,
SRT (MJPEG format is not
supported), Multicast, etc.
USB Features
Operate System
Windows 7, Windows 8,
Windows 10, Mac OS X,
Linux, Android
Color System/
Compression
MJPG/YUY2/H.264
Video Format
YUY2: 1080P@60fps
(max.)
H.264 AVC:
1080P@60fps (max.)
MJPEG: 1080P@60fps
(max.)
USB Audio
Support
USB Video
Communication
Protocol
UVC 1.1
UVC PTZ Support
Input/Output Interface
Network
Interface
1 x NET: 10M/100M
Adaptive Ethernet Port
USB Interface 1 x USB 3.0: Type-C
LINE IN Interface
1 x LINE IN: 3.5mm Audio
Interface
Communication
Interface
1 x RS232: 8pin Min DIN,
Max. Distance: 30m,
Protocol: VISCA/Pelco-D/
Pelco-P
HDMI Output
Interface
1 x HDMI 1.4b
Power Jack
JEITA type (DC 12V)
/USB Type-C (USB 5V)/PoE
General Specifications
Input Voltage
DC 12V/USB 5V
/PoE (802.3af)
Input Current
12V 1.0A (max.)
/5V 1.5A (max.)
Operating
Temperature
-10°C ~ 40°C
Storage
Temperature
-40°C ~ 60°C
Power
Consumption
12W (max.)
Dimension 142.2 x 151.9 x 175.8 (mm)
Net Weight 1.5Kg
