USB HD Video Conference Camera User Manual
2
2) Connect the power adapter to the power
connector on the rear panel of the camera.
The power indicator on the front panel of the
camera is on.
3) After the camera is powered on, it starts to
initialize, right up to the limit position, and
then both horizontal and vertical go to the
middle position, the motor stops running,
and the initialization is completed.
4 About Product
4.1 Features
Full Function USB Interface
Full function USB interface, compatible with USB
3.0 and USB 2.0, support UVC v1.1 and UAC 1.0
protocol, support video raw image and encoding
output.
1080P Full HD
High-quality HD CMOS sensor with 2.07 million
effective pixels for high-quality images up to
1920x1080.
72.5° Wide-angle-lens +16x Digital Zoom
The exclusively customized 72.5° high-quality
ultra-wide-angle lens, support 12x optical zoom
and 16x digital zoom.
Low Illumination
The new CMOS image sensor with ultra-high SNR
can effectively reduce the image noise under low
illumination. The application of 2D and 3D noise
reduction algorithm greatly reduces the image
noise even under the condition of ultra-low
illumination, it keeps the picture clean and clear,
and the SNR of image is as high as 55dB.
PoE
The wired network supports PoE power supply,
the control, power supply, video and audio can
be completed with a network cable.
Remote Control
The camera can be controlled remotely through
the RS232, network and USB port.
H.264 Slice
The H.264 stream supports Slice encoding modes,
and suitable for high-end USB conference video
applications.
Dual Stream
Support two stream output (YUY2, MJPEG, H.264
each of both) to reduce the host codec pressure.
Multiple & Complete Interfaces
Support 1080P video output through HDMI, USB
3.0 and network simultaneously.
Three Power Supply Modes
Simultaneously support USB 5V, DC 12V power
adapter and PoE power supply.
High Frame Rate
1080P output frame rate up to 60fps.
4.2 Product Specification
Camera
Video System
1080P/60, 1080P/50
，
1080/P30, 1080P/25，
720P/60, 720P/50
Sensor
1/2.8 inch, CMOS,
Effective Pixel: 2.07M
Scanning Mode Progressive
Lens
12x, f=3.5mm ~ 42.3mm,
F1.8 ~ F2.8
Digital Zoom 16x
Minimum
Illumination
0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s ~ 1/10000s
White Balance
Auto, Indoor, Outdoor,
One Push, Manual, VAR
Backlight
Compensation
Support
Digital Noise
Reduction
2D&3D Digital Noise
Reduction
Signal Noise
Ratio
≥55dB
Horizontal Angle
of View
72.5° ~ 6.9°
Vertical Angle of
View
44.8° ~ 3.9°
Horizontal
Rotation Range
±170°
