Robot Coupe CMP 250 V.V. handleiding
Handleiding
Je bekijkt pagina 8 van 41
9
• TUBE AND BELL
There are two ways to proceed:
Simple cleaning procedure
Submerge the tube and bell in water and run for a
few seconds to clean. Unplug the power cord.
Complete cleaning procedure
Unplug the power mixer and rinse the bell under
a water tap. Remove the bell from the tube, then
remove the blade (wear cutting gloves) ! Be
careful to avoid damaging the surface of the blade
shaft and the watertight seals. Always dilute the
detergent/disinfectant (see above). Thoroughly dry
all parts before reassembling.
• BLADE
The blade can be removed from the bell for
thorough cleaning. Always dry thoroughly to avoid
spotting.
• ALUMINUM
Use soft-metal-safe cleaning agents!
• PLASTIC
Be careful, many cleaning agents are corrosive
and are not safe for use on plastics!
Do not use strong alkaline detergent (having a
high concentration of soda or ammonia).
• WHISK HOLDER
Never immerse the whisk holder in water. Clean it
with a cloth lightly dampened (not dripping). Never
run the whisk holder through a dishwasher.
• Removing the whisk from the whisk holder
While griping the
ejector
A
in one
hand and the holder
B
in the other, pull
the ejector in the
opposite direction of
the arrow.
• Removing the ejector
Hold the whisk by the
wires
B
in one hand.
With the other hand,
pull the ejector
A
in
the direction of the
arrow (see figure).
SPLASH GUARD ASSEMBLY
- Put the screw back on the
ring and tighten it.
Cover the ring with the
splash guard protection
sliding it all along the foot
C
in the arrow
1
direction,
the flange
D
must be
oriented down.
BE CAREFUL: align the front
sides of the two parts.
- To remove the splash guard
protection for cleaning
follow these instructions in
the reverse order.
A
B
A
B
CLEANING
• MOTOR HOUSING
The power mixer must be clean through all stages
of production. Clean between each job using a
detergent or disinfectant. Dilute the detergent/
disinfectant following the instructions normally
specified on it’s packaging container. Use a
cloth lightly dampened (not dripping) with the
cleaning solution. Do not allow liquid to come into
contact with the electrical components contained
within the housing. Be careful when cleaning
around vents do not allow liquid to drip or seep
into the housing. Use a cloth lightly dampened
(not dripping) with water to remove detergent/
disinfectant then dry using a clean cloth.
After using the power mixer in a hot mixture,
cool the bottom of the tube in cold water before
disassembling the bell from the tube.
Clean immediately after use to prevent product from
sticking to surfaces.
WARNING
Never immerse motor housing and/or handle
in liquid! The housing contains the electrical
components and is not sealed against liquid.
Contact with liquid can cause damage to the
blender and serious injury to the operator.
WARNING
• Always unplug the power mixer before
cleaning it!
• Always dilute bleach according to the
instructions on the label
• Never run the motor assembly through a
dish machine.
• The type and concentration of the sanitation
agent must comply with 21 CFR 178.1010
regulations.
• Clean according to local health department
regulations.
