7
- Unplug the machine then, align the flat side of
A
the conical part of the tube with catch
B
in the
aluminum casing.
- Insert the narrow portion of conical part
C
of the
tube into the aluminum casing.
- Turn the tube in the direction of the arrow (see
figure) until it is snugly in place.
• Removing the tube from the casing
- Unplug the power mixer.
- Turn the tube in the opposite direction of that used
to attach it.
- When it will not go any further, remove the tube
from the conical part.
ASSEMBLY / DISASSEMBLY
- BLADE
• Attaching the tube to the motor unit.
(only for CMP Combi)
Always make sure that the bell is completely immersed
to avoid splashing and that the ventilation openings
in the motor housing do not come into contact with
any liquid!
For optimum efficiency two thirds (
2
/
3
) of the tube
should be immersed in the product.
• WHISK OPERATION
We recommend that you hold the power mixer by
the handle and the bottom of the motor unit.
You can also hold
the appliance by the
handle with one hand,
leaving the other hand
free to hold the bowl, if
necessary.
While processing we
recommend that you
move the whisk around
in the bowl, in order
to ensure that the
mixture is completely
homogeneous. We
strongly advise you to
keep the whisk from
touching the sides of
the bowl. For maximum
efficiency, at least
one-fifth of the whisk
length should be im-
mersed. We also
strongly advise you to
start the processing at a
low speed.
• Attaching the bell to the tube
- Unplug the power mixer.
- Align the flat side of
A
the conical part of the
tube with catch
B
on the inside of the bell.
- Insert the conical part
C
into the bell. With the
washer touching the tube seal
D
, turn the bell in
the direction of the arrow (See figure) to lock the
bell lug
E
and tube lug
F
snugly together.
TURN TO ATTACH
BELL
