10
Operating Instructions
DEFAULT TIMING
All of the cooking zones have a default timing function. The cooking zones will automatically turn off after this time
has elapsed. See the table below to see the times for the different power levels.
Power Level
1 2 3 4 5 6-9
Default timing
6h 6h 5h 5h 4h 1.5h
HIGH TEMPERATURE WARNING
• Press and hold power button manually for 3s till switch off, the whole appliance will stop heating, but the
cooking surface still has high temperature, the indicator digital tube of corresponding cooking zone which
stop heating will show residual heat warning symbol “ ”, to indicate corresponding cooking surface high
temperature.
• As long as the cooking zone has heated before, the high temperature warning symbol “ ” will display for 35
minutes continually after the hob turn off.
PROTECTION FUNCTION
• High temperature protection: When the temperature of the burner is too high, the mechanical
temperature limit protection device of the burner starts to protect, stops heating, and resumes heating after
the temperature drops.
• Residual heat protection: When the whole appliance stops heating, the digital tube of the relative heating
zone will display high temperature warning symbol “ ”, indicating that cooking surface temperature is too
high, please do not touch to avoid getting burned.
• Safety cut-off protection: For the models with plug, when cut off after 1S at any time, the voltage
between L/N of the plug should fall to below safe voltage range.
• Connection of display board and power supply board breakdown: When the appliance is switched on,
if the display board does not receive the correct power board signal for 20 consecutive seconds, the timer
digit digital tube will display " " and all loads stop working. It will return to shut down mode after 1
minute, and display will continuously show high temperature warning symbol “ ” for the one which under
residual heat protection.
How to use the Cooktop
Put the pot in the centre of the cooking zone. Use a pot with a flat bottom with a diameter the same as the cooking
zone.
Shut down: after using, please turn the knob to “OFF”, the hob will stop heating.
CAUTION!
• Ensure the heating plate is clean-a soiled zone does not transfer all the heat.
• Protect the plate against corrosion.
• Switch off the plate against corrosion.
• Do not leave pans with prepared dishes based on fats and oils unattended on the switched-on plate; hot
fat can spontaneously catch fire.
