Rinnai 28 GD OIM
CHANGING DOOR OPENING DIRECTION
The dryer access door may be swapped from a left handed opening as supplied from the factory to a right handed
opening. When changing door opening direction ensure the appropriate clearances are provided. Refer to Position
the appliance in accordance with the requirements listed under "Appliance Location" on page 24. for clearance
details.
1. Carefully insert a small at headed screwdriver into the upper gap (as shown above) and gently pry the hinge
cover towards the direction of the marking, until the upper tab is unclipped from its slot.
Repeat the above process in the lower gap until the lower tab is unclipped from its slot.
Once both tabs have been unclipped, use your ngers to carefully pull the hinge cover o in the direction of
the
marking(s) until removed. DO NOT discard the hinge cover, as it will be reinstalled in step 8.
2. While holding onto the door to prevent it from dropping, remove the two hinge mounting screws.
3. Lift the door upwards o the locating tabs, and place both the door and screws safely to one side.
1
Tab
Tab
Lower Tab
Upper Tab
When unclipping the lower tab, insert a
small flat head screwdriver into this gap
When unclipping the upper tab, insert a
small flat head screwdriver into this gap
Hinge Cover
2
3
Hinge Mounting Screws
Hinge Mounting Tabs
GENERAL INSTALLATION INFORMATION
