A BNC connector that is used to output the 10 MHz clock signal generated by the
internal crystal oscillator inside the instrument.
2. 10 MHz REF IN
A BNC connector that is used to input the external reference clock signal.
3. Battery Pack Snap-Fit Slot
Used to insert the battery pack snap-fit part to fasten the battery pack.
4. HDMI
Connects the instrument to an external display that has the HDMI interface (e.g.
monitor or projector) via this interface to better observe the waveform display
clearly. At this time, you can also view the waveforms on the LCD of the
instrument.
5. USB DEVICE
Connects the instrument to the PC via this interface. Then you can use the PC
software to send the SCPI commands or use the user-defined programming to
control the instrument.
6. LAN
Connects the instrument to network via this interface. The instrument is in
compliance with the standards specified in LXI Device Specification 2011. It can be
used to set up a test system with other standard devices. Then you can control the
instrument through using Web Control to send the SCPI commands. When update
is available, you can perform online upgrading for the system software of the
instrument via the LAN interface.
7. Security Lock Hole
Use a standard PC/laptop lock cable to secure the oscilloscope to a work bench or
other location.
8. Screw Mounting Hole
Used for securing the instrument to the bracket of the PC.
9. AC Power Cord Connector
The rated AC power source supported by the instrument is 100-240 V, 50-60 Hz.
Please use the power cord provided in the accessories to connect the instrument
to the AC power source.
10. Fuse
If you need to replace the fuse, use only the specified fuse.
11. Battery Pack Interface
Used to connect the battery pack.
12. Battery Pack Mounting Slot
Quick Start
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
29
