TIP
When the search function is enabled,
Zoom Mode (Delayed Sweep)
is automatically enabled.
Select the Search Type
Select "Edge" or "Pulse" as the search type.
• Edge search: After selecting "Edge" as the search type, set the edge type and
threshold. For detailed setting methods, refer to
Edge Trigger
.
• Pulse search: After selecting "Pulse" as the search type, set the pulse polarity,
search condition, and threshold. For detailed setting methods, refer to
Pulse
Trigger
.
Set the Source
Selects an analog channel as the source of the search function.
Copy Trigger
• To Trigger
Click or tap
To Trigger to copy the selected search type settings to the same
trigger type. For example, if the current search type is "Edge", click or tap To
Trigger to copy the edge search settings to "
Edge Trigger
" settings.
•
From Trigger
Click or tap From Trigger to copy the trigger settings to the specified search
type settings. For example, if the current search type is "
Edge Trigger
", click or
tap
From Trigger to copy the Edge trigger settings to the "Edge" search settings.
NOTE
If you select "From Trigger", you need to set the search type first, and then copy the
trigger type settings from the trigger menu.
Enable or Disable the Mark Table
When the mark table is enabled, the mark table is displayed, as shown in the figure
below. The mark table lists the mark events of the waveforms displayed in the current
waveform view. When you zoom or pan to adjust the waveforms, the events in the
mark table will change. You can perform the following operations on the mark table.
• When the instrument is in STOP state, click or tap any row in the mark table to
select the specified event. The upside-down triangle that marks the selected
event turns red (
).
Search and Navigation Function
MHO2000 User Guide
262
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
