When the operating status of the instrument is STOP, you can export the time and
corresponding decoding data from the current event table.
Click or tap Export to enter the file export interface. You can export the data list to
the internal memory or the external USB storage device (when detected) in "*.csv"
format. The detailed export operation is similar to the save operation, you can refer to
relevant descriptions in
To Store and Load
.
Interpret the FlexRay Decoding Frame Structure
• TSS: Transmit Start Sequence, displayed as "TSS:".
• Sync Frame: displayed as "SYNC:".
• ID (Frame ID): expressed in Hex, displayed as "ID:".
• PL (Payload Length): expressed in Hex, displayed as "PL:".
• HCRC (Header Cyclic Redundancy Check): expressed in Hex, displayed as
"HCRC:". When errors occur, it is displayed as a red patch.
• CYC (Cycle Number): expressed in Hex, displayed as "CYC:".
• Data: Its display format is the same as that of the bus data (Hex, Dec, Bin, or
ASCII), displayed as "Data:".
• TCRC (Tail Cyclic Redundancy Check): expressed in Hex, displayed as "TCRC:".
When errors occur, it is displayed as a red patch.
19.9 1553B Decoding (Option)
The oscilloscope samples the 1553B signal, and judges each data point to be logic "1"
or logic "0" according to the preset threshold level. 1553B decoding is required to
specify the data channel source and the threshold.
In the Decode menu, click or tap the drop-down button of Bus Type to select 1553B,
then configure the parameters for 1553B decoding.
Protocol Decoding
MHO2000 User Guide
250
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
