Set the Event Table Format
Click or tap the drop-down button of Format to select the display format of the event
table. The available formats include "Hex", "Dec", "Bin", and "ASCII".
Export
When the operating status of the instrument is STOP, you can export the time and
corresponding decoding data from the current event table.
Click or tap
Export to enter the file export interface. You can export the data list to
the internal memory or the external USB storage device (when detected) in "*.csv"
format. The detailed export operation is similar to the save operation, you can refer to
relevant descriptions in
To Store and Load
.
Interpret the LIN Decoding Frame Structure
• Break (Sync Break): expressed in Hex, displayed as "Break:".
• SYNC (Sync): expressed in Hex, displayed as "SYNC:".
• ID (Frame ID): expressed in Hex, displayed as "ID:".
• Data: Its display format is the same as that of the bus data (Hex, Dec, Bin, or
ASCII), displayed as "Data:".
• Checksum: expressed in Hex, displayed as "Checksum:". When errors occur, it is
displayed as a red patch.
• Wakeup: displayed as "Wakeup".
19.7 I2S Decoding (Option)
The oscilloscope samples the I2S signal, and judges each data point to be logic "1" or
logic "0" according to the preset threshold level. I2S decoding is required to specify
the serial clock, channel signal, and the data's source channel. You need to set
Alignment, WS Low, and other parameters.
In the Decode menu, click or tap the drop-down button of Bus Type to select I2S,
then configure the parameters for I2S decoding.
Protocol Decoding
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
243
