When the source is set to an analog channel, click or tap the input field of
Threshold to set the threshold for the specified channel with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
threshold.
• The available channels for MOSI include analog channels, digital channels, and
OFF.
When the source is set to an analog channel, click or tap the input field of
Threshold to set the threshold for the specified channel with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
threshold.
NOTE
The MISO and MOSI sources cannot be set to "OFF" at the same time.
19.4.2 To Set the Mode and Data
Mode
Click or tap "Timeout" or "CS" under Mode.
• Timeout:
you can perform frame synchronization according to the timeout, and the
timeout value must be greater than half of the clock cycle. Click or tap the input
field of
Timeout to set the timeout value with the pop-up numeric keypad. You
can also use the specified knob to set it. The adjustable range of the timeout
value is from 8 ns to 10 s. By default, it is 1 μs.
• CS:
contains a chip select line (CS). You can perform frame synchronization
according to CS. When "CS" is selected,
- Click or tap drop-down button of CS to select the desired source from the
drop-down list. The available channels include digital channels and analog
channels.
- When the source is set to an analog channel, click or tap the input field of
Threshold to set the threshold with the pop-up numeric keypad. You can
also use the specified knob to set the threshold.
- In CS Polarity menu, click or tap to select "Positive" or "Negative".
Protocol Decoding
MHO2000 User Guide
234
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
