17.4 To Export and Import the Reference Waveform
Export to Internal or External Memory
After saving the reference waveform, the reference waveform will be saved to the
internal memory or external USB storage device. The format of the reference
waveform file can be "*.ref", "*.bin", or "*.csv".
Click or tap
Export to enter the reference waveform file exporting interface.
• Set the Format
In the file exporting interface, click or tap the drop-down button of
Format to
select "*.ref", "*.bin", or "*.csv" as the file format.
• Set the Filename
Click or tap the input field of File Name, then filename editing interface is
displayed.Input the filename with the pop-up numeric keypad.
For the methods of using the numeric keypad, refer to descriptions in
Parameter
Setting Method
.
• Set the File Path
Click or tap the input field of File Path, then the disk management interface is
displayed. Through the disk management menu, you can save the current
reference waveform to the internal memory or external USB storage device. After
selecting the desired storage path, click or tap
Export to export the desired file.
For the disk management operation, refer to descriptions in
Disk Management
.
TIP
• Only when the reference waveform is saved, can this export function be valid.
• This series oscilloscope only supports the flash memory USB storage device of FAT32
format.
• For the "*.bin" format file, refer to "
Binary Data Format (.bin)
".
Import from Internal or External Memory
You can import the stored reference waveform file from the internal memory or
external USB storage device to the internal instrument and display the file on the
screen.
Click or tap
Import to enter the reference waveform file importing interface.
• Set the Format
In the file importing interface, click or tap the drop-down button of
Format to
select "*.ref" as the file format.
• Set the Import Path
Reference Waveform
MHO2000 User Guide
212
