15.2 Ampl/Freq Setting
Click or tap the Ampl/Freq Setting tab to enter the Ampl/Freq Setting menu. Then
set the following parameters.
• Start Frequency: click or tap the input field of Start Freq to set the start
frequency of the Sine waveform with the pop-up numeric keypad. You can also
use the specified multifunction knob to set the value. The settable range is from
10 Hz to 3 MHz.
• Stop Frequency: click or tap the input field of Stop Freq to set the stop
frequency of the Sine waveform with the pop-up numeric keypad. You can also
use the specified multifunction knob to set the value. The available range of stop
frequency is from 100 Hz to 30 MHz. Stop Frequency ≥ 10 x Start Frequency.
• Points/Decade: click or tap the input field of
Points/Decade to set the number
of displayed points per decade. You can also use the specified multifunction
knob to set the value. The setting range is from 10 to 100. By default, it is 10.
• Amplitude: click or tap the input field of
Amp to set the voltage amplitude of
the Sine waveform when the Var.Amp. is set to "OFF".
• Variable Amplitude: click or tap the ON/OFF tab for Var.Amp. to enable or
disable the variable amplitude. When enabled, you can set the voltage amplitude
of the Sine waveform under different frequency ranges.
TIP
The stop frequency shall be greater than the start frequency.
15.3 To Save and Load the Bode Plot File
Click or tap the Save tab to enter the save setting interface. Here you can save and
load the Bode plot data.
Save the Test Data
1. Click or tap the drop-down button of Format to select the format of the saved
Bode plot. The available file types include "*.csv" and "*.html".
2. Click or tap the input field of
File Name to input the filename with the pop-up
virtual keypad.
3. Click or tap the input field of File Path, and then the "Disk" interface is displayed.
Select the desired destination path, and then click or tap OK to confirm the
operation. For details about the disk management, refer to
Disk Management
.
4. Click or tap Save to save the Bode plot file according to the settings.
Bode Plot
MHO2000 User Guide
202
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
