13.4 To Set the Histogram Height
The histogram height indicates the number of grids that fall into the bar of the
histogram graph.
In the histogram setting interface, click or tap the input field of Height to set the the
height of the histogram with the pop-up numeric keypad.. The range of the
histogram height is from 1 div to 4 div. By default, it is 2 div.
13.5 To Set the Histogram Range
When the histogram type is set to Vertical or Horizontal, you need to set the
histogram range. Set "Left Limit", "Right Limit", "Top Limit", and "Bottom Limit"
respectively to adjust the size and position of the histogram.
Click or tap the input field of the specified limit to set the limit of the histogram with
the pop-up numeric keypad. You can also use the specified knob indicated in the
input field of the specified limit to set it. You also directly drag the left, right, top, or
bottom edge of the white histogram diagram window to adjust the position and size
the histogram.
NOTE
The adjustment for the horizontal time base and vertical scale will not affect the histogram
range, but only shows variation with the change of the scale.
13.6 Histogram Analysis Results
When the histogram function is enabled, the histogram result is displayed in the
"Result" list at the right section of the screen. The test result includes the following
test items:
• Sum: indicates the sum of all bins (buckets) in the histogram.
• Peaks: indicates the maximum number of hits in any single bin.
• Max: indicates the value that corresponds to the maximum bin that has any hits.
• Min: indicates the value that corresponds to the minimum bin that has any hits.
• Pk_Pk: indicates the Delta between the max. value and the min. value.
• Mean: indicates the average value of the histogram.
• Median: indicates the median value of the histogram.
• Mode: indicates the mode value of the histogram.
• Bin width: indicates the width of each bin (bucket) in the histogram.
• Sigma: indicates the standard deviation of the histogram.
• µ±σ: indicates the proportion of the number of frequencies or counts of the
histogram hits that lie within one standard deviation of the mean to the total
number of histogram hits. μ indicates the mean value in normal distribution. It is
Histogram Analysis
MHO2000 User Guide
180
